Technical Data - Scheppach MPT3400-4PGE Originalanleitung

serviced periodically. Damages must be repaired by a
service center.
– Only use accessories recommended by the manufac-
turer.See Maintenance/Accessories
– Never use metal multi-piece cutting blades, cutting tools
with spinning chains or flail blades.
– Have your tool serviced only by qualified personnel and
by use of original spare parts only. This ensures that
the tool will work safely in the future.
Residual risks
• There will always be residual risks, even if you use
this equipment according to instructions. The fol-
lowing hazards can occur in connection with the con-
struction and design of this tool.
• Health hazards resulting from swinging of hand and
arm if the equipment is used for an extended period
and if it is not operated or maintained properly.
• Injuries and material damage caused by ejection of
tool attachments which are unexpectedly thrown from
the equipment because of sudden damage, wear and
tear or improper attachment.
• Warning! This tool generates an electromagnetic field
during operation. Under certain circumstances, this
field can affect active or passive medical implants. In
order to reduce the risk of severe or fatal injuries, we
recommend that people with medical implants consult
their doctor and the manufacturer of the medical im-
plant before operating the machine.
• Always start the cut with the saw chain running. Make
the cut in such a way that the saw does not get jam-
med in the wood.
• Use the gripping spikes for every cut as the starting
point and always start the cut with the saw chain run-
ning. Make the cut in such a way that the saw does
not get jammed in the wood.
• Pay particular attention to branches under tension.
• Always pull the tool out of the wood when the saw
chain is running.
• Never work with the tool above shoulder height or
with only one hand.
• Always stand away from the falling direction. Position
yourself on a slope above the tree to be felled.
• Always stand sideways when carrying out sawing
work on a tree which is located on a slope, never
work from above or below.
• Always look out for the falling direction of the parts
which are cut off.
• Never start the cut with the bar tip and never cut with
the bar tip.
• Risk of kickback! There is always a risk of kickback
when the bar tip touches the wood or other objects.
This makes the chainsaw uncontrollable and it may
be thrown towards the operator with great force.
• Do not use the tool as a lever to move objects.
• Always use the chain guard during transport and sto-
rage.
• Secure the tool during transport in order to prevent
loss of fuel, damage or injury.
• Warning!
• Keep passers-by away from running equipment but
never work by yourself.
• Keep within earshot of others in case you need help.
• Stop the engine immediately when someone approa-
ches you.
• Make sure that the saw chain does not come in con-
tact with foreign objects such as stones, fences, nails
and similar. These objects could be ejected and injure
the operator or passers-by or damage the saw chain.
• National specifications may restrict the use of the po-
le saw.
• Do not use the pole-mounted pruner and the hedge
trimmer within 10 metres of high-voltage cables.
Before working on the tool itself (e.g. transport, set-
up, retooling, cleaning and maintenance), discon-
nect the spark plug cap!
Always attach the transport guard straight away.

6. Technical data

MPT3400-4PGE
Technical data
Cutting data grass trimmer
Cutting circle diameter of line mm
Cutting line diameter mm
Cutting line length m
Maximum speed grass trimmer min
Cutting data brush cutter
Cutting circle diameter of blade mm
Cutter balde thickness mm
Teeth quantity
Maximum speed brush cutter min
Cutting data hedge trimmer
Cutting circle diameter mm
Angle adjustment °
Cutting length mm
Max. cutting speed max. min
-1
Cutting data pole saw
Guide bar length mm
Cutting length mm
Guide bar type
Chain pitch "
Saw chain type
Chain link thickness mm
Oil tank capicity cm
3
Power unit
Displacement cm
3
Max. engine output kW
Idle speed min
-1
Fuel tank capicity cm
3
Engine type
Weight grass trimmer kg
Weight brush cutterr kg
Weight pole saw kg
Weight hedge trimmer kg
Subject to technical changes!
Information concerning noise
according to relevant standards:
430
2 x 2.4
4
5900
-1
255
1.4
3
7200
-1
24
+90°/0°/-75° (165°)
400
1550
305
254
Oregon
100SDEA318
3/8"
91PJ040X
1.27
125
32.6
0,9
3000
±200
900
2-stroke engine, air-
cooled
7.2
7.2
7.1
7.7
emission measured
GB 31
