-- The idle speed will decrease (-)
The idle speed is 3000 rpm.
Contact the manufacturer if the cutting tool still continues to
move in idle.
Do not continue working with the tool!
The user is responsible for all damages caused by
non-compliance with instructions in this manual.
This also applies to non-authorized modifications
of the tool, use of non-authorized spare parts,
accessories, working tools, unrelated and not
intended use, secondary damages due to use of
faulty components.
Wear Parts
Even when used in the intended way, some components
are subject to normal wear. They have to be replaced
depending on the kind of duration of usage. These parts
include, among others, the cutting tool and the retaining
disk.
m Warning!
Use only original manufacturer's replacement parts,
accessories and attachments. Failure to do so can
cause poor performance, possible injury and may void
your warranty.
Important hint in case of sending the equipment to a
service station:
Due to security reasons please see to it that the
equipment is sent back free of oil and gas!
Ordering replacement parts
Please quote the following data when ordering
replacement
parts:
• Type of machine
• Article number of the machine
Replacement parts / accesories:
For the cutting equipment listed here, you can always use
the safety guards provided with the unit.
Grass trimmer/brush cutter:
Spool with Ø 450
Blade with 3 teeth Ø 255 x 1.4
Transport guard for blade 3 teeth 3904801065
Blade with 4 teeth Ø 255 x 1.4
Transport guard for blade 4 teeth 3904801066
Blade with 8 teeth Ø 255 x 1.4
Transport guard for blade 8 teeth 3904801066
Safety shield for grass trimmer
Pole pruner:
Saw chain Oregon 91PJ040X
Guide rail Oregon 100SDEA318
Transport guard for chain
Extension for pole pruner
Hedge trimmer:
Blade for hedge trimmer 400 mm
Transport guard for blade
7910700701
7910700702
7910700705
7910700711
3904801023
7910700704
3904801037
3904801039
7910700710
7910700703
3904801043
11. Storage
Cleaning
• Keep handles free of oil, so you always have a secure hold.
• Clean the equipment as required with a damp cloth
and, if necessary, mild washing up liquid.
m Important!
• Always pull out the spark boot plug each time before
carrying out any cleaning.
• Never immerse the equipment in water or other liquids
in order to clean it.
• Store the petrol multi garden tool in a safe and dry
place out of the reach of children.
Storage
Important: Never put the equipment into storage for
longer than 30 days without carrying out the following
steps.
Storing the equipment
If you intend to store the equipment for longer than 30
days, the equipment must be prepared accordingly.
Otherwise the fuel still remaining in the carburetor will
evaporate and leave a rubbery sediment. This can cau-
se problems when starting up the equipment and may
require expensive repairs.
1 Slowly remove the fuel tank cap to release any pres-
sure that may have formed in the tank. Carefully empty
the tank.
2 To remove the fuel from the carburetor, start the engine
and let it run until the equipment stops.
3 Leave the engine to cool (approx. 5 minutes).
4 Remove the spark plug (see section 10 Change and
clean the spark plug).
5 Add one teaspoon of 2-stroke engine oil into the com-
bustion chamber. Slowly pull the starter cord several
times to apply a layer of oil to all internal components.
Fit the spark plug again.
Note: Store the equipment in a dry place and far away
from possible ignition sources such as an oven, a gas-fi
red hot water boiler, a gas-fi red dryer, etc.
Putting the equipment back into operation
1 Remove the spark plug (see section 10 Change and
clean the spark plug).
2 Quickly tug on the starter cord to remove excess oil
from the combustion chamber.
3 Clean the spark plug and check that the electrode gap
is correct, or insert a new spark plug with the correct
electrode gap.
4 Prepare the equipment for operation.
Transport
If you want to transport the tool, empty the petrol tank as
described in Chapter 8. Remove major dirt from the unit
with a brush.
Always attach the transport guard to all cutting tools.
Fig. 1 (14a, 15a, 17a)
In order to prevent damage and injury, secure the tool
against tipping over and sliding when transporting it in
vehicles.
