• 8 optically isolated inputs for thermocouple
• Thermocouples type J K
• 16 optically isolated digital outputs
• 1 optically isolated frequency input 1,5kHz
This section contains the instructions necessary for correct
installation of the GILOGIK II into the machine control panel
or the host system and for correct connection of the system
power supply, inputs, outputs and interfaces.
Before proceeding with installation read the following
warnings carefully!
Remember that lack of observation of these warnings
could lead to problems of electrical safety and electroma-
gnetic compatibility, as well as invalidating the warranty.
Qualified staff
the installation and use of the system and components are only reserved
at qualified staff.
Conform use
the system and relative components are usable exclusively to the use
previewed in the manual
In order to guarantee a correct and sure operation are indispensable that
the product comes transported, stored correctly, installed, and controlled
second the previewed modalities.
Suitable for use in pollution degree 2 environment.
Open type equipment.
Notes Concerning Electrical Safety and Electromagnetic
Compatibility:
Inputs
The inputs of the R-TC8 can be configured as follows:
Inputs for thermocouples
- analog temperature inputs with 24bit A/D conversion
Types of temperature sensors selectable via software:
- TC type J, (0.0 - 800.0°C / 1470.0°F)
- TC type K, (0.0 - 1200.0°C / 2190.0°F)
• Maximum input frequency 2,5Hz
• Input impedance > 1MΩ
Accuracy better than 0,5%
Temperature acquisition frequency: 200ms max.
Room temperature compensation: software on board module
Thermocouple input isolation: > 2 kV
4
R-TC8
MODULE 8 TEMPERATURE LOOPS
INSTALLATION AND OPERATION MANUAL
cod. 80131B / Edit 03 - 05/08 - ENG
1 • MAIN FEATURES
I
2 • INSTALLATION AND CONNECTION
3 • TECHNICAL DATA
I
• Software configuration of TC inputs
• Diagnostics LEDs for power supplies, outputs, and alarm
• Removable connector supplied
• CE MARKING: EMC Conformity (electromagnetic compatibility)
in accordance with EEC Directive 89/336/CEE modified by Directive
93/68. The GILOGIK II system is mainly designed to operate in
industrial environments, installed on the switchboards or control panels
of productive process machines or plants.
As regards electromagnetic compatibility, the strictest generic standards
have been adopted, as indicated in the table below.
• UL listed standard: UL508 file E198546
• BT Conformity (low tension)
in accordance with Directive 73/23/CEE modified by Directive 93/68.
Advice for Correct Installation for EMC
Inputs and outputs connection
• The externally connected circuits must be doubly isolated.
• To connect the analogue inputs the following is necessary:
- physically separate the input cables from those of the power supply, the
outputs and the power connections.
- use woven and screened cables, with the screen earthed in one point
only.
GEFRAN S.p.A. declines all responsibility for any damage
to persons or property caused by tampering, neglect,
improper use or any use which does not conform to the
characteristics of the controller and to the indications
given in these Instructions for Use.
Digital input to measure period and frequency
- 1 optoisolated digital input 24VDC ± 25%
- Maximum input voltage 32Vdc, 25mA max
- Protection against inversion of polarity
- Input trigger:
• maximum voltage for "0" (input OFF) = 12Vdc
• minimum voltage for "1" (input ON) = 15Vdc
- 1,5kHz input filter
Outputs
24Vdc ± 25% optically isolated digital outputs
- Organization: 1 group of 16 outputs
- Maximum voltage for outputs 32 V
- Maximum current for output 2 A
- Maximum total current 6 A
80131B_MHW_R-TC8_0508_ENG
