7
Operation
7.1
Initial operation
Connect the angle plug of the 8-pin data cable to the 8-pin connector of the probe together. If you hear a
clicking noise, the device is in the correct position. Now connect the other end of the 8-pin data cable to
the 8-pin connector of the ultrasonic hardness tester. Match with the positions of the groove and put them
together. When you hear a clicking sound, the connections are correct.
7.2
Measurement
To perform a measurement, follow these steps:
1. Press "Power"
turned on. You will reach the main menu then.
2. Press the "Scale"-Button to select the measurement scale and press the "ETR"-button. The
measurement mode will start then. After that the symbol
3. Hold the probe with both hands vertikal to the test object. Press down the inspection atamp until
the measurement tip is not visible anymore and the protective ring is lying flat on the test
material.
Manual
, and move the "ON/OFF" switch to "ON", so that the power supply is
14
is displayed.
