13.15 Button Lock

13.16 Headset connection

The connector is located under the protective rubber cover on the top of the unit.To attach
the external speaker/microphone headsets or earpiece, lift the rubber flap on the top of the
unit to expose the connector.
Insert the appropriate plug into the connector.

14 Technical specifications

PMR
Channels
CTCSS
Frequency
Range
Batteries PMR
Transmission Power
Modulation Type
Channel spacing
Channel Frequency Chart:
Channel Frequency (MHz)
1 446,00625
2 446,01875
3 446,03125
4 446,04375
5 446,05625
6 446,06875
7 446,08125
8 446,09375
Topcom Twintalker 6800
Downloaded from www.Manualslib.com
• Press and hold
LOCK mode. The BUTTON LOCK icon is displayed on the LCD Screen.
• Press and hold
CTCSS Code Chart
Code Frequency (Hz)
0
1
2
3
4
5
6
7
8
9
manuals search engine
for 3 seconds to activate or deactivate the BUTTON
again to deactivate BUTTON LOCK
8
38
446.00625MHz - 446.09375 MHz
Up to 6 Km (Open field)
4 x AAA Alkaline or NiMh rechargeable
=< 500mW ERP
FM - F3E
12,5 Khz
Code Freq. (Hz)
Disabled 10
67,0 11
71,9 12
74,4 13
77,0 14
79,7 15
82,5 16
85,4 17
88,5 18
91,5 19
Topcom Twintalker 6800
Code Freq. (Hz)
94,8 20 131,8
97,4 21 136,5
100,0 22 141,3
103,5 23 146,2
107,2 24 151,4
110,9 25 156,7
114,8 26 162,2
118,8 27 167,9
123,0 28 173,8
127,3 29 179,9
Code Freq. (Hz)
30 186,2
31 192,8
32 203,5
33 210,7
34 218,1
35 225,7
36 233,6
37 241,8
38 250,3
