Parts List
Ersatzteilliste
Parts List
En
Parts # Description
6122 Body Pin (Medium/10pcs)
6819 Silicone O-ring P-3 (Red/5pcs)
80550 HPI TF-1 transmitter without crystal (2ch/AM27MHz)
80559 HPI SF-1 servo (standard torque)
80569 HPI RF-6 receiver without crystal (AM 27MHz/2ch)
86896 Ball Stud 4.8x12mm (10pcs)
100329 Nylon Tie Strap 2.4x94mm (10pcs)
100550 Pan Head Screw M5x8mm (hex socket/10pcs)
101053 Screw M3 x 14mm
101160 Differential Case Bullet
101205 Diff Case
101206 Center Diff Housing Set
101207 54T Spur Gear MT/ST
101208 Upright Set
101209 Front Hub Carriers (10Degrees)
101210 Chassis Brace Set
101211 Rod End Set
101212 Shock Parts Set (Pr)
101213 Suspension Arm Set
101215 40T Diff. Gear
101216 13T Input Gear
101219 Rear Lower Arm Brace Orange
101220 Front Lower Arm Brace Orange
101221 Diff Case Gasket (3pcs)
101222 Shock Bladder (4pcs)
101223 Servo Saver Posts 5x35mm
101225 Ball 5.8x5mm (5pcs)
101226 Steering Nut 3mm (4pcs)
101227 Flange Pipe (4pcs)
101228 Axle 5x40mm (Pr)
101229 Gear Shaft 5x29mm (Pr)
101230 Diff Shaft 5x23.5mm (Pr)
101231 Cup Joint (F) 4.5x18.5mm
101232 Cup Joint (R)4.5x18mm
101233 Slipper Gear Shaft 6x43.5mm
101234 Drive shaft 6x72mm
101235 Drive shaft 6x83mm (Pr)
101236 Drive shaft 6x84mm (Pr)
101237 Turnbuckle M3.5x25mm
101238 Turnbuckle M3.5x53mm (Pr)
101239 Pin 1.7x11mm (10pcs)
101240 Shock Shaft 3x52mm (Pr)
101241 Slipper Clutch Hub (F)
101242 Slipper Clutch Hub (R)
101243 Slipper Clutch Spring 7x9x1.7mm 3coils
101244 Spring 13.5x63x1.2mm 11coils (2pcs)
101245 TP. Flat Head Screw M3*14mm (10pcs)
101246 TP. Button Head Screw M3*19mm (10pcs)
101248 Cap Head Screw M2.6x14mm (10pcs)
101249 TP. Button Head Screw M2.6*12mm (10pcs)
101250 Slipper Clutch Pad (2pcs)
101252 Bullet ST Wheels Black Chrome (Pr)
101253 Ball 5.8x14mm (5pcs)
101261 Trimmed and Painted Body Bullet Flux MT
101262 Trimmed and Painted Body Bullet Flux ST

Option Parts List

En
Parts # Description
80601 Crystal Set (Brown AM 26.995Mhz)
80602 Crystal Set (Red AM 27.045Mhz)
80603 Crystal Set (Orange AM 27.095Mhz)
80604 Crystal Set (Yellow AM 27.145Mhz)
80605 Crystal Set (Green AM 27.195Mhz)
80606 Crystal Set (Blue AM 27.255Mhz)
101267 ALUM.CNC Front Gearbox Plate
101268 ALUM.CNC Front Anti-bending plate set
101269 ALUM. CNC Rear anti-bending plate set
101270 Bullet 3.0 CVD shaft set
101283 8T Bullet Flux Pinion
101284 9T Bullet Flux Pinion
101286 11T Bullet Flux Pinion
101287 12T Bullet Flux Pinion
101291 Gearbox Spacer Set
101318 Bullet MT Clear Body
101319 Bullet ST Clear Body
Downloaded from www.Manualslib.com
Liste des Pièces
パーツリスト
manuals search engine
Parts # Description
101273 TP. Flat Head Screw M2.6x12mm (12pcs)
101285 10T Bullet Flux Pinion
101293 Body Mount Set
101294 Shock Body Set (2sets)
101295 Front Bumper Set
101296 Rear Bumper Set
101298 Diff. Gear Set
101299 3*51.8mm Front Inner Suspension Shaft (2pcs)
101300 3*56.3mm Rear Inner Suspension Shaft (2pcs)
101301 Diff. Shaft Set
101302 3*25mm Front Outer Suspension Shaft (2pcs)
101303 3*35.3mm Rear Outer Suspension Shaft (2pcs)
101305 Wheel Spacer Set (4pcs)
101306 Shock Tower (2pcs)
101307 Bullet ST Tyres (2pcs)
101308 Bullet MT Ammunition Tyres (2pcs)
101309 Bullet MT Wheels Black Chrome (Pr)
101312 Radio Tray(Rx+Battery),Radio Tray Lid(Battery) Bullet Flux
101313 Servo Arm,Radio Tray post,Radio Tray Lid(Rx) Bullet Flux
101314 Servo Top Deck Bullet Flux
101315 Centre Top Deck Bullet Flux
101316 Chassis Bullet Flux
101317 Center Bulkhead Motor Mount Bullet Flux
A020 O-Ring P5 Black (4Pcs)
A046 O-Ring P3 Black (4Pcs)
A133 Ball 5.8x6mm (4pcs)
B021 5x10x4 Bearing (pr)
B030 Ball Bearing 10x15x4mm (2pcs)
Z150 Aerial Tube
Z224 M3x8mm Washer (10pcs)
Z241 E Clip E2.5mm (20pcs)
Z242 E Clip E2mm (20pcs)
Z263 Pin 2x8mm (12pcs)
Z517 Binder Head Screw M3x8mm (10 pcs)
Z527 Flat Head Screw M3x10mm (6pcs)
Z538 Cap Head Screw M3x25mm (6pcs)
Z542 Cap Head Screw M3x8mm (12pcs)
Z543 Cap Head Screw M3x10mm (6pcs)
Z552 TP. Button Head Screw M3x10mm (10pcs)
Z553 TP. Button Head Screw M3x12mm (6pcs)
Z554 TP. Button Head Screw M3x15mm (10pcs)
Z558 TP. Button Head Screw M3x28mm (10Pcs)
Z561 TP. Flanged Screw M3x10mm (6pcs)
Z579 TP. Flat Head Screw M3x15mm (12pcs)
Z581 TP. Flat Head Screw M3x18mm (10pcs)
Z663 Nylon Nut M3 (6pcs)
Z669 Lock Nut M6 Thin Type (5pcs)
Z684 Flange Nylon Lock Nut M4 (4pcs)
Z700 Set Screw M3 x 3mm (6pcs)
Z721 Set Screw M4 x 4mm (4pcs)
Z800 Spring Washer 3mm (20pcs)
