Menu line Selection Submenu
Menu EXPOSURE
DC DC-controlled iris BRIGHT
LENS
MANUAL Manual iris BRIGHT
1/50, 1/100, 1/120FLC,
E. SHUTTER —
1/250 ... 1/100000
AGC OFF, LOW, MIDDLE, HIGH —
NO, X 2, X 4, X 8, X 16, X 32,
SENSE UP —
X 64, X 128, X 256
OFF —
BLC
ON LEVEL
OFF —
LWDR
LEVEL
Increase of contrast
OFF>ON
range in case of ON, AUTO
ON>OFF
poor illumination
DELAY TIME
DWDR OFF, LOW, MIDDLE, HIGH —
OFF —
HLC Highlight
Compensation
ON LEVEL
AUTO LEVEL
DNR Digital Noise ON LEVEL
Reduction
OFF —
RETURN — —
Menu WHITE BALANCE
ATW —
MANUAL RED
MANUAL
WB MODE MANUAL BLUE
AWC —
R – Y GAIN — —
B – Y GAIN — —
RETURN — —
Menu DAY&NIGHT
COLOR>BW
AUTO
BW>COLOR
D&N MODE
DELAY TIME
COLOR —
B&W —
OFF, ON
BURST —
Burst signal
DYNAMIC IR MODE 1, MODE 2, OFF —
RETURN — —
Bold type = ex-factory
®
MONACOR INTERNATIONAL GmbH & Co. KG • Zum Falsch 36 • 28307 Bremen • Germany
Adjustment; Function
0 . . 46 . . . . . 100; picture brightness
0 . . 46 . . . . . 100; picture brightness
Shutter speed; 1/120FLC = flicker-free, when flickering occurs in artificial light
gain control range, with OFF the day /night mode is not switched over
automatically
increase of the light sensitivity in case of low illumination
no compensation
(BLC = Backlight compensation = Gegenlichtkompensation)
0 . . 10 . . 20; brightness level of objects
in front of a bright background (e. g. window)
no increase of contrast
0 . . 30 . . 60; level of contrast increase
0 . . 60 . . 70; brightness at which the function is activated
0 . . 80 . . 100; brightness at which the function is deactivated
1 . . . 3 . . . 15; delay of activation/deactivation
increase of the contrast range by evaluating several pictures
with different shutter speeds (DWDR = Digital Wide Dynamic Range)
highlight compensation deactivated;
function to blacken bright light sources (e. g. spotlights) to be able to
reproduce objects (e. g. number plates) in a clearly visible way
0 . . 10 . . 60; threshold of blackening
0 . . 10 . . 60; threshold of blackening; for night operation only!
0 . . 12 . . 20; reduction of the picture noise in case of low illumination
return to the main menu
automatic white balance in the colour temperature range 2500 – 9500 K
manual white balance by adjusting the gain for the colours red and blue
(0 . . 100 . . . 255)
for a white balance at the present colour temperature hold a white sheet of
paper in front of the camera and press down the control lever.
0 . . . 128 . . . 255; colour intensity red part
0 . . . 128 . . . 255; colour intensity blue part
return to the main menu
45 . . . 70 . . . 160; brightness at which the camera is switched from day to
night mode by the AGC
30 . . . 55 . . . 145; brightness at which the camera is switched from night to
day mode by the AGC
3 . . . . . 5 . . . . 12; delay for the day/ night switching
always day mode (colour reproduction, IR LEDs off)
always night mode (B&W reproduction, IR LEDs on)
OFF = prevents disturbing coloured noise in the B&W picture
ON = if the monitor needs the signal for synchronization
compensation of overexposure of close objects with lit IR LEDs
return to the main menu
Menu line Selection Submenu
Menu IMAGE ADJUST
FLIP OFF, HORI —
SHARPNESS — —
GAMMA — —
RETURN — —
Menu ALARM
OFF —
DISPLAY
MOTION SET WINDOW
ON
ALL SET
ALL CLEAR
SENSITIVITY
HOLD TIME
RETURN — —
Menu PRIVACY ZONE
OFF —
MASK 1— 8
Cover of SET WINDOW
picture areas by
ON
8 masks max.
COLOR SET
RETURN — —
Menu SPECIAL
LANGUAGE ENGLISH, DEUTSCH —
OFF —
EDIT
TITLE RESET
ON
POSITION
RETURN
OFF —
DPC Defect Pixel WHITE THR
Correction
AUTO BLACK THR
DPC LEVEL
SYNC INT —
MONITOR CRT, LCD —
COMMUNICATION — ...
FACTORY SET — —
RETURN — —
Menu EXIT
SAVE AND EXIT — —
EXIT — —
RETURN — —
Copyright © by MONACOR INTERNATIONAL. All rights reserved.
Adjustment; Function
mirror function
0 . . . 18 . . . 50; picture sharpness
0.45, 0.6, 1.0, USER; gamma correction = adaptation of the brightness levels
in the video signal to human perception
return to the main menu
motion detection function deactivated
MESSAGE; when a motion is detected, the message MOTION is displayed
NONE; no message is displayed
For motion detection up to 240 sensor fields can be activated in the camera
picture: Select a field with the control lever and activate the field (shows blue)
or deactivate it by pushing down the lever.
To exit the adjusting window, select a field at the right edge and tilt the lever to
the right or select a field at the left edge and tilt the lever to the left.
All sensor fields are activated.
All sensor fields are deactivated.
0 . . . . 100; sensitivity of response
1 . . . . . 15; time of the display
return to the main menu
no cover
Tilt the control lever to move the mask. Push down the lever: Now it is pos-
sible to change height and width of the mask. Push down the lever again:
The marked corner of the mask can be moved. Push down the lever to select
the other three corners successively and tilt the lever to move them. Then
push down the lever again to exit the adjusting window.
mask colour:
BLUE, GREEN, CYAN, RED, MAGENTA, YELLOW, GRAY, BLACK
return to the main menu
selection of the menu language
no camera name inserted
input of 16 characters max.
cancel the name
define position of camera name
return to the menu SPECIAL
no correction
0 . . . . . . 160 . . 255; correction sensitivity for white pixels
0 . . 10 . . . . . . . 255; sensitivity of correction for black pixels
0 . . 10 . . . . . . . 255; level of correction
internal synchronization, no further options
tube or LCD monitor connected
adjustments w / o function (remote control of camera)
reset all adjustments ex-factory, except LENS, LANGUAGE, MONITOR and
COMMUNICATION
return to the main menu
save adjustments and extinguish menu
do not save adjustments and extinguish menu
return to the main menu
