10. Technical specifications
RJ45
868 MHz radio
Analogue input
Digital inputs
Digital outputs
Relay contacts
46 / 168
RouterNode 2, GatewayNode 2,
Network interface

10T/100T

HP Auto_MDX

DHCP-Client (DHCP: on)

IPv4

Service

TCP: 1x at Port 2101
¬
UDP: 1x for Digi-Scan
¬
(OAM tool)
Web server: Enable

WaveNet interface
1x with 12-bit resolution from 0 to
3.3 V
DC
3x. An external contact connec-
ted to VOUT changes the logic
state from 0 to 1.
Low/Logical 0: 0 V

0.8 V
DC
High/Logical 1: 2.0 V

3.3 V
DC
Maximum voltage: 4.1 V

2x open drain.
1x change-over contact, poten-
tial-free.
SmartBridge
to
DC
to
DC
DC
