RouterNode 2, GatewayNode 2,
SmartBridge
Connection
DC In
IO-V
out
RJ45
ANT
Connection
Analogue input
Unused
DI 3
DI 2
EN
NOTE
IO connector only for RouterNode 2
You can only use the connectors of the IO connector
at RouterNode 2.
Pin connector
Terminal block: GND
Terminal block: +3.3
V
Meaning
Power supply with
round plug connector
Auxiliary voltage out-
put - Earth connec-
tion
Auxiliary voltage out-
put - Positive pole
Network connection
Connector for ex-
ternal antenna (see
Antenna)
Meaning
Connection of an analogue signal
from 0 V to 2.5 V
DC
Unused.
The connection of a digital signal
from 0 V to 3.3 V
DC
The connection of a digital signal
from 0 V to 3.3 V
DC
4. Connections
.
DC
.
DC
.
DC
