Graduations on the LCD screen indicate the levels selected.
IMPORTANT: Detection distances vary depending on the length of antenna wire laid out on the property. The longer the antenna wire, the
narrower the zones.
The width of the warning and stimulation zones also vary according to the selector position.
NOTE: the stimulation zone cannot be wider than the warning zone.
The following tables indicate the approximate widths of the zones for a 800 m and a 300 m installation, with the selector in position "large ground":
LCD screen
LCD screen
IMPORTANT: the widths indicated are approximate and vary depending on the configuration of each installation.
The following tables indicate the approximate widths of the zones for a 300 m and a 100 m installation, with the selector in position "small
ground":
LCD screen
Downloaded from www.Manualslib.com
800 m installation, selector position « large ground »
Zones setting
(levels)
MINIMUM warning = 1
MAXIMUM warning = 40
MINIMUM stimulation = 0
MINIMUM warning = 15
MAXIMUM warning = 40
MAXIMUM stimulation = 8
300 m installation, selector position « large ground »
Zones setting
(levels)
MINIMUM warning = 1
MAXIMUM warning = 9
sounds are emitted permanently)
MINIMUM stimulation = 0
MINIMUM warning = 8
MAXIMUM warning = 9
MAXIMUM stimulation = 5
sounds and stimulations are emitted perma-
nently)
300 m installation, selector position « small ground »
Zones setting
(levels)
MINIMUM warning = 1
MAXIMUM warning = 40
MINIMUM stimulation = 0
MINIMUM warning = 21
MAXIMUM warning = 40
MAXIMUM stimulation = 8
manuals search engine
Gb - 20
Approximate width of the zones
on each side of the wire
MINIMUM warning ~ 0 m
MAXIMUM warning ~ 4.1 m
No stimulation area.
Only beep sounds are emitted.
MINIMUM warning ~ 2 m
MAXIMUM warning ~ 4.1 m
MAXIMUM stimulation ~ 2 m
Approximate width of the zones
on each side of the wire
MINIMUM warning ~ 3.5 m
MAXIMUM warning ~ 16 m
No stimulation area.
Only beep sounds are emitted.
MINIMUM warning ~ 12.8 m
MAXIMUM warning ~ 16 m
MAXIMUM stimulation ~ 11.40 m
Approximate width of the zones
on each side of the wire
MINIMUM warning ~ 0 m
MAXIMUM warning ~ 2.8 m
No stimulation area.
Only beep sounds are emitted.
MINIMUM warning ~ 1.3 m
MAXIMUM warning ~ 2.8 m
MAXIMUM stimulation ~ 1.3 m
