Attaching Adapter Plate to Screen with VESA

or 200 x 200 Mounting Pattern
NOTE: For VESA 75 mm and 100 mm patterns, see following page.
Attach hook bracket (M) to adapter plate (N) using
3
four M5 x 6 mm screws (K) and #10 washers (L) as
shown.
• If screws don't get three complete turns in the screen inserts or if screws bottom out and adapter plate is still not
tightly secured, damage may occur to screen or product may fail.
®
FOR VESA
3-1
Choose hole pattern as shown below. Attach
adapter plate (N) to back of screen using four M4 x
10 mm screws (E) as shown below.
*NOTE: If screw (E) gets less than three threads
of engagement, attach adapter plate (N) to back of
screen using four M4 x 20 mm screws (F) and four
spacers (C) as indicated below.
Skip to step 4 on page 9.
N
E
Downloaded from www.Manualslib.com
200 x 100 MOUNTING PATTERN:
*For screens with a
hole pattern in a pocket,
spacers (C) go between
adapter plate (N) and
screen.
manuals search engine
®
200 x 100
K
WARNING
FOR VESA
Choose hole pattern as shown below. Attach
adapter plate (N) to back of screen using four M6 x
12 mm screws (G) as shown below.
*NOTE: If screw (G) gets less than three threads
of engagement, attach adapter plate (N) to back of
screen using four M6 x 20 mm screws (I). If screw
(I) still gets less than three threads of engagement,
use four M6 x 30 mm screws (J).
Skip to step 4 on page 9.
N
G
C
7 of 46
N
L
M
®
200 x 200 MOUNTING PATTERN:
ISSUED: 01-15-08 SHEET #: 095-9282-2 06-12-09
