ECtemp Next Plus HW
1 Introduction
ECtemp Next Plus HW is an electronic programmable timer
thermostat used for controlling domestic hot water temperature.
The thermostat is designed for fixed installation only and can be
used for both temperature maintenance and legionella mitigation
(above 55 °C), using timer and external sensor features.
• Correct wiring is essential. Use instrument to confirm L
and N before wiring is recommended.
• Don't remove too much of the insulation cover from
the wire to avoid short circuit, caused by the naked wire
touching the metal 86 mm. sized mounting wall box.
• Don't let the screw press or touch the wire when using
screw to fix room thermostat in wall box. A short-circuit
risk exists if the wire insulation cover is damaged by the
screw, and if the naked wire connects with the screw.
• If walls must be painted, mount the room thermostat
after painting, to avoid dust or paint material penetrating
the room thermostat and thus damaging the PCB.
• The max load of relay is <16 A (resistive) or <6 A (inductive).
The relay will be damaged if the load exceeds the limit.
• Don't cover the thermostat, for instance by
hanging towels directly in front of it.
