SPECIFICATIONS

SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS
Item
Broadcasting systems
Colour systems
Channels and frequencies
Sound-multiplex systems
Teletext systems
Power requirements
Power consumption
Picture tube size
Audio output
Speakers
EXT-1 terminal
EXT-2 terminal
EXT-3 terminal
EXT-4 terminal
Headphone jack
Dimensions (W × H × D)
Weight
Accessories
* A basic model number. The actual model number may have characters added (such as "S" denoting silver) indicating the colour
of the TV set.
Design and specifications subject to change without notice.
Pictures displayed on the screen using this TV's ZOOM functions should not be shown for any commercial or demonstration pur-
pose in public places (cafes, hotels, etc.) without the consent of the owners of copyright of the original picture sources, as this
constitutes an infringement of copyright.
Downloaded from www.Manualslib.com
Model
CCIR B/G, I, D/K, L
PAL, SECAM
• The EXT terminals also support the NTSC 3.58/4.43 MHz system.
• E2-E12, E21-E69, S1-S41, X, Y, Z, Z+1, Z+2, ITALY A-H, ITALY H+1, ITALY H+2, F2-F10,
F21-F69, R1-R12, R21-R69
• French cable TV channel of broadcast frequencies 116 - 172 MHz and 220 - 469 MHz
A2 (B/G, D/K), NICAM (B/G, I, D/K, L) system
FLOF (Fastext), TOP, WST (World Standard System)
220 - 240 V AC, 50 Hz
Maximum: 165 W, Average: 112 W, Standby: 2.8 W
Viewable area 66 cm (measured diagonally)
Rated Power output: 5 W + 5 W
(10 cm × 3 cm) oval × 2
Euroconnector (21-pin, SCART)
• Video input, Audio L/R inputs and RGB inputs are available.
• TV broadcast outputs (Video and Audio L/R) are available.
Euroconnector (21-pin, SCART)
• Video input, S-VIDEO (Y/C) input, Audio L/R inputs and RGB inputs are available.
• Video and Audio L/R outputs are available.
• T-V LINK functions are available.
Euroconnector (21-pin, SCART)
• Video input, S-VIDEO (Y/C)input and Audio L/R inputs are available.
RCA connectors × 3
S-VIDEO connector × 1
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
Stereo mini-jack (3.5 mm in diameter)
725 mm × 480 mm × 496 mm
34.7 kg
Remote control unit × 1 (RM-C54 (Grey) or RM-C50 (Black) is supplied.)
AAA/R03 dry cell battery × 2
manuals search engine
AV28CH1EU*
