Specifications - JVC Natural Vision T-V LINK AV32T20EP Bedienungsanleitung

Specifications

Item
Broadcasting systems
Colour systems
Channels and frequencies
Sound-multiplex systems
Teletext systems
Power requirements
Power consumption
Picture tube size
Audio output
Speakers
EXT-1 terminal
EXT-2 terminal
EXT-3 terminal
EXT-4 terminal
AUDIO OUT terminal
Headphone jack
Dimensions (W × H × D)
Weight
Accessories
*: A basic model number. The actual model number may have characters added (such as "S"
denoting silver) indicating the colour of the TV set.
Design and specifications subject to change without notice.
Pictures displayed on the screen using this TV's ZOOM functions should not be shown for any
commercial or demonstration purpose in public places (cafes, hotels, etc.) without the consent of
the owners of copyright of the original picture sources, as this constitutes an infringement of
copyright.
42
Model
AV32T20EP*
CCIR B/G, I, L
PAL, SECAM
• The EXT terminals also support the NTSC 3.58/4.43 MHz system.
• E2-E12, E21-E69, S1-S41, X, Y, Z, Z+1, Z+2, ITALY A-H, ITALY H+1, ITALY
H+2, F2-F10, F21-F69
• French cable TV channel of broadcast frequencies 116 - 172 MHz and 220 -
469 MHz
A2 (B/G), NICAM (B/G, I, L) system
FLOF (Fastext), TOP, WST (World Standard System)
220 - 240 V AC, 50 Hz
Maximum: 180 W, Average: 120 W, Standby: 3 W
Viewable area 76 cm (measured
diagonally)
Rated Power output: 10 W + 10 W
(16 cm × 4 cm) oval × 2
Euroconnector (21-pin, SCART)
• Video input, Audio L/R inputs and RGB inputs are available.
• TV broadcast outputs (Video and Audio L/R) are available.
Euroconnector (21-pin, SCART)
• Video input, S-VIDEO (Y/C) input, Audio L/R inputs and RGB inputs are
available.
• Video and Audio L/R outputs are available.
• T-V LINK functions are available.
Euroconnector (21-pin, SCART)
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
RCA connectors × 3
S-VIDEO connector × 1
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
RCA connectors × 2
• Variable audio L/R outputs are available.
• Variable out 0-1 Vrms, low impedance
Stereo mini-jack (3.5 mm in diameter)
855 mm × 550 mm × 568 mm
54.7 kg
Remote control unit × 1 (RM-C54 (Grey) or RM-C50 (Black) is supplied.)
AAA/R03 dry cell battery × 2
AV28T20EP*
Viewable area 66 cm (measured
diagonally)
780 mm × 509 mm × 499 mm
38.6 kg
