Computer signals (preset)
DVI-D (HDCP) terminals
No. Signal name
1 VGA60
2 WVGA60
3 SVGA60
4 XGA60
5 WXGA (1280)
6 WXGA+60*
4
7 SXGA60*
4
8 WSXGA+60*
4
9 UXGA60*
4
10 WUXGA60*
4
11 720/60p
12 1080/60p*
4
13 720/50p
14 1080/50p*
4
For DT-R17L4D: When No. 6-10, 12 or 14 signals come in, thin lines will become obscured because their signal resolution is higher than the
*4
screen resolution.
• Non-preset signals may not be displayed normally even if their frequency is within the acceptable range (☞ "Horizontal/vertical frequency
(computer signal)" on page 24).
• When a preset signal comes in, the signal format is shown on the status display. For other signals, the resolution is shown.
Specification of the DVI-D (HDCP) terminal
Connect it to the DVI-D output terminal on a personal computer.
Pin
No.
1 T.M.D.S Data 2–
2 T.M.D.S Data 2+
3 T.M.D.S Data 2 shield
4 NC
5 NC
6 DDC Clock
7 DDC Data
8 NC
