Warranty
The warranty conditions issued by our relevant sales
company apply in all countries. We shall remedy possi-
ble malfunctions on your appliance within the warranty
period free of cost, provided that a material or manufac-
turing defect is the cause. In a warranty case, please
contact your dealer (with the purchase receipt) or the
next authorised customer service site.
(See overleaf for the address)

Technical data

Electrical connection
Voltage
Phase
Frequency
Power rating
Degree of protection
Protection class
Power protection (slow-blowing)
Water connection
Feed pressure (max.)
Input temperature (max.)
Input amount (min.)
Suction height (max.)
Device performance data
Operating pressure
Max. permissible pressure
Water flow rate
Maximum flow rate
Detergent flow rate
High-pressure gun recoil force
Dimensions and weights
Typical operating weight
Length
Width
Height
Determined values in acc. with EN 60335-2-79
Hand-arm vibration value
Uncertainty K
Sound pressure level L
pA
Uncertainty K
pA
Sound power level L + K uncer-
WA
tainty
WA
Subject to technical modifications.

EU Declaration of Conformity

We hereby declare that the machine described below
complies with the relevant basic safety and health re-
quirements in the EU Directives, both in its basic design
and construction as well as in the version placed in circu-
lation by us. This declaration is invalidated by any chang-
es made to the machine that are not approved by us.
Product: High-pressure cleaner
Type: 1.324-xxx
Currently applicable EU Directives
2000/14/EC
2014/30/EU
V 230
~ 1
Hz 50
kW 2,1
IPX5
I
A 10
MPa 1,2
°C 40
l/min 10
m 0,5
MPa 12,5
MPa 14,5
l/min 7,5
l/min 8,3
l/min 0,3
N 20
kg 14,8
mm 402
mm 306
mm 588
2
m/s <2,5
2
m/s 0,6
dB(A) 76
dB(A) 3
dB(A) 92
Français
2006/42/EC (+2009/127/EC)
2011/65/EU
Harmonised standards used
EN 50581
EN 55014-1: 2017
EN 55014-2: 2015
EN 60335-1
EN 60335-2-79
EN 61000-3-2: 2014
EN 61000-3-3: 2013
EN 62233: 2008
Conformity evaluation procedure used
2000/14/EC: Appendix V
Sound power level dB(A)
Measured: 89
Guaranteed: 92
The undersigned act on behalf and under the power of
attorney of the company management.
H. Jenner
Chairman of the Board of Management
Documentation supervisor:
S. Reiser
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Ph.: +49 7195 14-0
Fax: +49 7195 14-2212
Winnenden, 2018/10/01
Contenu
Remarques générales.........................................
KÄRCHER Home & Garden App ........................
Protection de l'environnement.............................
Utilisation conforme.............................................
Accessoires et pièces de rechange ....................
Etendue de livraison............................................
Description de l'appareil ......................................
Dispositifs de sécurité .........................................
Symboles sur l'appareil .......................................
Montage ..............................................................
Mise en service ...................................................
Fonctionnement ..................................................
Transport .............................................................
Stockage .............................................................
Dépannage en cas de pannes ............................
Caractéristiques techniques................................
Déclaration de conformité UE .............................

Remarques générales

Veuillez lire le présent le manuel d'ins-
tructions original et les consignes de sé-
curité jointes avant la première
utilisation de l'appareil. Suivez ces instructions.
Conservez les deux manuels pour une utilisation ulté-
rieure ou pour le propriétaire suivant.
KÄRCHER Home & Garden App
KÄRCHER Home & Garden App contient :
● des informations sur le montage et la mise en ser-
vice
● des informations sur les domaines d'application
S. Reiser
Director Regulatory Affairs & Certification
15
15
16
16
16
16
16
17
17
17
17
18
19
19
20
20
21
