Technical Data

1) Link LED (green)
2) Activity LED (yellow)
3) Status LED (green)
4) USB port 8
5) USB port 7
Properties
Device connection
Network connection
Operating environment
Dimensions
Current input
Quick Installation Guide
Downloaded from www.Manualslib.com
6) USB port 6
7) USB port 5
8) USB port 4
9) USB port 3
10) Reset button
Values
- 8 x USB 2.0 HS
logical: - IEEE 802.3
physical: - RJ-45 (STP Cat. 5)
- Ambient temperature:
- Relative humidity:
- Length:
- Width:
- Height:
- Weight:
- 200 mA @ 12 VDC (without load)
- 2500 mA @ 12 VDC (full load on the USB ports)
manuals search engine
11) USB port 2
12) USB port 1
13) LEDs for USB ports 1-8
14) Power LED
15) Connector for the
included power pack
5 - 40 °C
20 - 80 %
155 mm
215 mm
45 mm
1050 g with housing cover
[en] 5
