Technical Data - SEH myUTN-800 Schnellstartanleitung

Technical Data

1) Network connector 1
(RJ-45)
2) Network connector 2
(RJ-45)
3) Activity LED (yellow)
4) Status LED (green)
Properties
Network connection
Device connection
Current input
Operating environment
Dimensions
Quick Installation Guide
5) Segment display
6) SD card reader
7) Reset button
8) Restart button
9) USB ports 1–20 with
USB port LEDs
Values
logical: - IEEE 802.3 (1000BaseT, 100BaseTX and 10BaseT)
physical: - 2 × RJ-45
- 20 × USB 2.0 Hi-Speed
- 1 × SD Card reader
per supply max 1.3 A at 100–240 VAC (with full load on the USB ports)
- Ambient temperature:
- Relative humidity:
- Width:
- Height:
- Depth:
- Weight:
(Suitable for 19" server racks.)
10) Power supply 1
11) Hole for the RMK3 cable
12) Power supply 2
5–40 °C
20–80 %
422 mm
44 mm
243 mm
2950 g with housing cover, without mounting
brackets
[en]
fixture
