Technical Data

Network connector
(RJ-45)
(at the rear side)
link LED activity LED
(green)
status LED
(green)
Properties
Network connector
Device connection
Current input
Power consumption
Operating environment
Dimensions
4
USB ports 1-8
with LED for the USB port
1
(yellow)
power LED
(green)
Values
logical: IEEE 802.3 (1000BaseT, 100BaseTX and 10BaseT)
physical: 1 × RJ-45 (STP, category 5 or better)
• 4 × USB 3.0 SuperSpeed (USB ports 1–4)
• 4 × USB 2.0 Hi-Speed (USB ports 5–8)
• approx. 200 mA at 12 V direct current without
load
• approx. 2500 mA at 12 V direct current with full
load on the USB ports
• approx. 2.6 W without USB dongles
• approx. 4.5 W with 8 USB dongles
• typ. approx. 40 kWh/year
ambient temperature:
relative humidity:
width:
height:
depth:
weight:
restart button
215 mm
45 mm
155 mm
1070 g (with housing cover)
[en]
power supply
connector
(at the rear side)
reset button
5–40 °C
20–80 %
Quick Installation Guide
