LED Display
The LEDs of the UTN server provide information about its status.
LED
Link
Activitiy
Status
USB Ports 1-8
6
Downloaded from www.Manualslib.com
Action Color
permanently on green
blinks at yellow
irregular
intervals
permanently off -
blinks 3 times green
blinks 2 times green
permanently off
permanently on green
permanently on orange
manuals search engine
Description
Indicates an existing connection to the network.
Indicates the receipt of data packets.
If the network activity LED blinks periodically at
the same time, the BIOS mode is signalized.
Indicates the assignment of a ZeroConfig IP
address.
Indicates the assignment of an IP address that
does not correspond to 0.0.0.0 or that comes
from outside the ZeroConf range.
Indicates that no USB dongle is connected to
the respective port.
Indicates that a USB dongle is connected to the
respective port.
Indicates that a USB dongle is enabled at the
respective port.
[en] Quick Installation Guide
