EINHELL FREELEXO Basic Originalbetriebsanleitung Seite 45

The alarm LED (55) is lit yellow
Fault
Too close to the
garage
Rolling over
Wheel slip
STOP button error
Anl_FREELEXO_Basic_SPK9.indb 45 Anl_FREELEXO_Basic_SPK9.indb 45
GB
Possible cause
- The robot lawn mower was
sent back too close to the
charging station (19).
- The robot lawn mower was
constantly tilted for 10 se-
conds
- The robot lawn mower has
been tilted for a prolonged
time in one direction
- The rear wheels (8) have
lifted due to an obstacle
- The rear wheels (8) can ro-
tate freely due to an uneven
lawn
The display cover (25) is open
but the STOP button (3) was
not pressed
- 45 -
Remedy
Press the STOP button (3) in order to open
the display cover (25). Re-start the mowing
operation on the control panel (2):
- The robot lawn mower should be sent
back to the charging station (19) at a mini-
mum distance of 2 m.
Press the STOP button (3) to open the dis-
play cover (25). Restart the mowing operati-
on via the control panel (2):
- Move the robot lawn mower to a level area
and restart it.
- If the robot lawn mower has tilted because
of a steep slope in the mowing area, ad-
just the perimeter wire (18) accordingly to
avoid severe inclines.
Press the STOP button (3) to open the dis-
play cover (25). Restart the mowing operati-
on via the control panel (2):
- Move the robot lawn mower to a level area
and restart
Press the STOP button (3) to open the dis-
play cover (25). Restart the mowing operati-
on via the control panel (2):
- Check whether the display cover (25)
can be opened and closed freely with the
STOP button (3).
- Check whether the STOP button (3) func-
tions correctly.
