General Setup Page * CLOSED CAPTIONS
Some discs have closed captions.
ON: Show the closed captions.
OFF: Hide the closed captions.
* SCREEN SAVER
To set screen saver ON or OFF.
AUTO STANDBY 3 H * AUTO STANDBY(Automatic turn off)
This function allows you to select the standby setting:
OFF: The unit will not switch to standby mode.
3 H: If no button is pressed within 3 hours, the unit will switch to standby mode
* TV DISPLAY: selects the aspect ratio of the playback picture.
automatically.
4:3 PANSCAN:
4 H: If no button is pressed within 4 hours, the unit will switch to standby mode
● When wide-screen video is played, this mode clips the right and left sides of the image
automatically.
so that it can be viewed on a conventional screen.
● Some wide-screen DVDs that do not permit Pan Scan mode playback are automatically
played in letterbox mode (black bands top and bottom). Analog Audio Setup Page
4:3 LETTERBOX:
● When wide-screen video is played in this mode on a conventional screen, black bands
appear at the top and bottom of the screen.
16:9: wide screen display.
● This is the correct mode for playing wide-screen videos on a wide-screen TV.
WIDE SQUEEZE
The wide-screen image will be displayed in full screen in its native aspect ratio and so
does the 4:3 image but with black borders on the left and the right side.
Notes:
● The visible picture size is preset on the DVD disc. Therefore the playback picture of
some DVD discs may not conform to the picture size you select.
* DOWNMIX
● When you play DVD discs recorded in the 4:3 aspect ratio, the playback picture
LT/RT: left and right soundtrack audio output.
will always appears in the 4:3 aspect ratio regardless of the TV shape setting in the
STEREO: Stereo audio signal output
function setup menu.
* DOLBY DIGITAL
* ANGLE MARK
DUAL MONO
ON: To show angle mark when a disc with multiple camera angles is playing. You can
To select STEREO, L-MONO (left mono), R-MONO (right mono) and MIX- MONO for
view different camera angles of a DVD disc by pressing ANGLE button on remote
Dolby Digital output.
control.
DYNAMIC
OFF: To hide angle mark.
● To control the different sound levels via dynamic compression. It improves the quality
NOTE: This function is only available for discs encoded with multiple camera angles.
of the sound track at a low volume, and quiets the loudest sounds.
●This function is available only on DVD discs recorded in Dolby Digital.
* OSD LANGUAGE
To select the language of unit's menus.
GB - 12
● No naked flame sources, such as lighted candles, should be placed on the
PLACEMENT
apparatus.
● The use of apparatus in moderate climates. Mounting bracket
● The apparatus should not be exposed to dripping or splashing.
● Ensure a minimum distance of 5cm around the apparatus for sufficient ventilation.
● Do not place objects filled with liquids, such as vases, on the apparatus.
● The marking plate is located on the back of unit.
● Attention should be drawn to the environmental aspects of battery disposal.
● Do not throw batteries in fire!
● Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
● Excessive sound pressure from earphones and headphones can cause hearing loss.
● Under the influence of electrical fast transient or/and electrostatic phenomenon, the
product may malfunction and require user to power reset.
MAINTENANCE
Cleaning
Be sure to turn the unit off and disconnect the car power adaptor before maintaining
the unit.
- Use a soft, dry, clean cloth. Regularly dust the vents at the back or sides.
- Using solvents, abrasive or alcohol-based products risks damaging the appliance.
Mounting in the Vehicle
- If an object or liquid enters inside the appliance, unplug it immediately and have it
Use the supplied car mounting brackets to install the main unit and monitor on the
checked by an authorized engineer.
back of the vehicle's headrests.
Note on disc
1. Remove the 4 screws on the headrest bracket. Fix the headrest bracket into the
* Do not use irregular shape CDs (example: heart-shaped, octagonal ones). It may
steel pipes of the vehicle's headrest using these screws.
result in malfunctions.
* Do not place more than one disc in the disc compartment.
* Do not try to open the disc compartment during playing.
* Do not touch the lens. Doing so may cause malfunction.
* If there is a scratch, dirt or fingerprints on the disc, it may cause tracking error.
Before playing, clean the disc with a cleaning cloth. Wipe the disc from the center
out. Don't store discs in places with high temperatures or high humidity, they can
become warped. After playing, store the disc in its case.
2. Fix the back holder and connecting shaft through the joint rotation fastening knob.
Important Note
● Before transporting the unit, remove the disc from the disc compartment.
GB - 18
DVP-3578 IB MUSE 001 REV2- GB.indd 2
Video Setup Page
GOTO VIDEO SETUP PAGE
* BRIGHTNESS: To adjust the video brightness level on a scale of -16 to +16.
* CONTRAST: To adjust the video contrast level on a scale of –16 to +16.
* HUE: To adjust the color hue level on a scale of –9 to +9.
* SATURATION: To adjust the color saturation level on a scale of -9 to +9.
* DIVX VOD
Some DivX Video-On-Demand files required registration code, please get the code of
your DVD player.
Registration code is for DivX Video-On-Demand only, do not apply this code for another
applications or websites.
Preference page
Noted: The preferences Setup menu is only available at stop mode.
MPEG4 SUBTITLE WES
GOTO PREFERENCE PAGE
* TV TYPE
● To select your TV system among PAL, AUTO or NTSC.
* AUDIO
● To select the dialog language.
● If the selected language is not available on the disc, the disc's language will be used
instead.
● To change the dialog language during playback, press AUDIO on the remote control.
GB - 13 GB - 14
3. Combine the holder into the headrest bracket.
Knob screw
4. Fix the main unit or monitor to the back holder using the knob screws.
Back holder
Headrest bracket
with screws
Connecting shaft
Joint rotation
fastening knob
Caution!
- Make sure the screws are properly locked to avoid accidental loosening.
- Always remember to lock the holder to ensure the safety of your passengers.
- Do not install when car travels.
5. Connect the 12V car plug as shown.
CAUTION: Using other car plugs could damage the unit.
GB - 19 GB - 20
* SUBTITLE * PASSWORD MODE
● To select the language of the DVD subtitles. Select "OFF" to turn off the subtitles. To turn the password mode ON/OFF.
● If the selected language is not available on the disc, the disc's language will be used
instead.
* PASSWORD
● To change the subtitle language during playback, press SUBTITLE on the remote control.
This option allows you to set or change the password.
Use ▼, ▲ button to select "PASSWORD", press ►button to highlight "CHANGE", then
* DISC MENU (menu language)
press the ENTER button. Press the number buttons to input your 4-digit password until
● To select the language of the DVD menus.
to "OK" (If the password has not been set yet after you purchase this unit, it is "1369").
● If the selected language is not available on the disc, the disc's language will be used
instead.
* PARENTAL SAFETY INSTRUCTION
Some DVD discs are equipped with a password function and are rated according to their
content. The contents allowed by parental lock level and the way a DVD disc is controlled
may vary from disc to disc. For example, if the disc allows, you could lock-out violent scenes
unsuitable for children or you could lock out playback of the disc altogether.
You cannot play DVD discs rated higher than the level you selected unless you cancel the
parental lock function.
The lightning flash with arrowhead symbol within the triangle is a warning sign
The parental lock levels are equivalent to the following ratings.
alerting the user of "dangerous voltage" inside the unit.
Level 1 : Kid Safe
Level 2 : G
Level 3 : PG The exclamation point within the triangle is a warning sign alerting the user
Level 4 : PG-13 of important instructions accompanying the product.
Level 5 : PG-R
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
Level 6 : R
APPLIANCE TO RAIN OR MOISTURE.
Level 7 : NC17
Level 8 : Adult
CAUTION: Invisible laser radiation when open and interlocks defeated. Avoid exposure
* MPEG4 SUBTITLE to beam.
If your MPEG4(DivX) video file includes subtitle file, use this to select your preferred subtitle Class 1 laser product.
language.
* DEFAULT
Pressing ENTER with this function selected resets all settings to their initial factory state,
except for parental level and password.
Password Setup Page.
GB - 15
Unit A Unit B
TROUBLE SHOOTING
No power.
● Ensure the car power adaptor is connected.
● Make sure that the unit is turned on.
The remote control does not function.
● Make sure the infrared remote sensor is not blocked.
● Point the remote directly at the infrared remote sensor on the unit.
● Replace the battery in the remote with a new one.
Car plug
Very little or no sound is coming from a DVD.
● Make sure that the unit is turned ON.
● Make sure the unit is not paused. Press
AV cable
● Make sure the unit is not in fast-forward or fast-reverse mode. Press
● Make sure that the connections are correct.
* Make sure the MUTE function is not on.
A Remote control B
The player does not start playback
● Insert the disc with the printed side facing you.
● Check that the disc can actually be played by this device.
SAFETY WARNING!
● Check that the disc's regional code matches the player's regional code. This player's
• On no account should this unit be used by the driver of a moving motor vehicle, or left
regional code is 2.
unsecured in the vehicle whilst driving.
● Clean the disc.
• If this unit is being used by a passenger in your vehicle, be sure that it is secured or
held safely, and does not obstruct any safety device (i.e. airbag, seat belt etc.) that is
The picture is not clear.
fitted.
● The DVD is dirty. Gently clean the disc.
• All passengers should wear seat belts when using this unit in a moving vehicle.
● The disc is scratched.
• If in doubt, please contact your vehicle manufacturer for further advice.
● Please adjust the LCD's brightness and contrast in LCD mode.
• Using other car power adaptors could damage the unit.
Forget Password
If you forget your own password, enter "1369" to reset.
Specifications and appearance are subject to change without notice.
GB - 21
IMPORTANT SAFETY PRECAUTIONS
SAFE USE OF YOUR EQUIPMENT
Here are a few tips to help you do this:
READ this instruction manual before you attempt to use the equipment.
NEVER fit make shift stands or legs with woodscrews. Use only approved supports and
fasteners specially designed for the equipment.
NEVER let anyone, especially children, push objects into holes, ventilation slots or any
other opening; this could result in fatal electric shock!
ALWAYS disconnect the Car power adaptor when you are not going to use the unit for
a long period of time.
ENSURE that all electrical connections (including the mains plug, extension leads and
interconnections between pieces of equipment) are properly made in accordance with the
ATTENTION: To reduce the risk of electric shock, do not remove
instructions given. Switch off the main supply when making or changing connections.
the cover or back. There are no user serviceable parts inside
CONSULT your dealer if you are ever in doubt about the installation, operation or safety
the unit. Refer all servicing to qualified personnel.
of your equipment.
DON'T continue to operate the equipment if it is damaged in any way or if it does not
function normally. Disconnect the Car power adaptor and consult your dealer.
DON'T leave equipment switched on when it is unattended unless it is part of it's normal
function to operate in your absence, for example a video cassette recorder with timed
recording facility.
LISTEN to headphones at moderate volume levels; high volume levels can permanently
damage your hearing.
WARNING:
● Car power adaptor is used as the disconnect device. It shall remain readily operable
and should not be obstructed during intended use. To be completely disconnected
the apparatus from supply mains, the car power adaptor of the apparatus shall be
disconnected from the mains socket outlet completely.
● Never use a power adaptor that is damaged, route power lead in a safe manner and
make sure it is not subjected to trapping or pinching. If the power lead is damaged
refer to a qualified service agent.
● Place the unit on a flat and even surface.
● Do not restrict the air flow of the unit by placing it in a place with poor air flow, by
covering it with a cloth, or by placing it on carpeting.
● To avoid magnetized, do not place the unit near speaker or magnet.
● Do not use this unit in direct sunlight or leave the unit in a closed automobile (or yacht,
etc) where it would be exposed to high temperatures above 40°C.
● It also should not be placed in temperatures less than 5°C or greater than 35°C.
● No naked flame sources such as lighted candles should be placed on the AC adaptor
and main unit.
● Do not use the unit immediately after transportation from a cold place to a warm place,
condensation problem may result.
● The ventilation should not be impeded by covering the ventilation openings with items
such as newspapers, table-cloths, curtains, etc.
GB - 16 GB - 17
.
.
NEW ONE S.A.S
10, Rue de la Mission, 25480 Ecole Valentin, France
GB - 22 GB - 23
M-995CVB/IB/V2
2016/8/12 10:55:28
