BENE T-PANEL CURVE Montageanleitung Seite 15

MONTAGE - T-PANEL EXTEND AN LIFT DESK, LEVEL LIFT PURE & LEVEL LIFT
ASSEMBLY - T-PANEL EXTEND ON LIFT DESK, LEVEL LIFT PURE & LEVEL LIFT
MONTAGE - T-PANEL EXTEND SUR LIFT DESK, LEVEL LIFT PURE & LEVEL LIFT
1
D990278
SPAX-SKPZ-SZ-4,0*20
1a
3
5
6
6x
Schraube lockern, einrichten dann fixieren.
7a
Loosen screw, set up then fix.
Dévisser vis, ajuster et fixer la vis.
D990379
GWSR-LKIS-VZ-M8*16
2
4
7
2x
8
90°
D990122
USCH-VZ-FM6-DIN134
D990963
SPAX-PHPZ-VZ-5,0/35
15
4x
4x
