3

System description

3.1

Structure

1) Sensor connection
2) Display
3) METRIC / IMPERIAL key (units)
4) HOLD key
5) Volume key
6) Earphone connection
7) Connection for RS-232 cable
8) FUNCTION key
9) FILTER key
10) On / off key
11) Battery compartment cover
12) Sensor
3.2

Delivery content

1 x vibration meter
1 x attachable sensor 1.5 m cable
1 x handle with 1.5 m cable
1 x 75 mm pin probes
1 x magnetic adaptor plate
3 x batteries
1 x carrying case
1 x manual
3.3

Optional accessories

Data cable
Software
ISO calibration certificate
Replacement measuring tip
4 Measuring functions (parameters)
4.1

Acceleration

Acceleration is measured in m/s² (F/s²). Acceleration measurement is particularly useful for the localisation of high-
frequency vibration and is therefore suitable for the determination of faults in bearings and gearboxes.
By means of the FILTER key, you can set the frequency.
Display: 1 kHz (10 Hz ... 1 kHz)
10 kHz (10 Hz ... 10 kHz)
(PCE-VT 2700)
(PCE-VT 2700S)
EN - 9
