1

Safety notes

Please read this manual carefully and completely before you use the device for the first time. The device may only
be used by qualified personnel and repaired by PCE Instruments personnel. There is no warranty of damages or
injuries caused by non-observance of the manual.
- The device may only be used in the approved temperature range.
- The case should only be opened by qualified personnel of PCE Instruments.
- The instrument should never be placed with the user interface facing an object (e.g. keyboard side on a
table).
- You should not make any technical changes to the device.
- The appliance should only be cleaned with a damp cloth / use only pH-neutral cleaner.
- The meter contains magentic components. Therefore, keep it away from people with cardiac pacemakers etc.
This manual is published by PCE Instruments without any guarantee.
We expressly point to our general guarantee terms which can be found in our general terms of business.
If you have any questions please contact PCE Instruments.
2

Specifications

Measurement range acceleration
Measurement range velocity
Measurement range displacement
Measurement range revolutions
Resolution
Accuracy
Frequency range acceleration
Frequency range velocity
Frequency range displacement
Display
Units
Interface
Power supply
Auto Power Off
Low Bat symbol
Operating conditions
Dimensions
Weight
EN - 8
0.0 ... 399.9 m/s² (Peak) / 0.0 ... 1311 ft/s² (Peak)
0.00 ... 399.9 mm/s (RMS) / 0.00 ... 15.75 inch/s (RMS)
0.000 ... 3.999 mm (Pk-Pk) / 0.000 ... 158.0 mil (Pk-Pk)
50 ... 99.900 rpm (reading must be multiplied by 10)
0.1 m/s²; 0.1 mm/s; 1 µm, 1 rpm
± 5% of reading + 2 digits
10 Hz ... 1 kHz (in 1 kHz mode) / 10 Hz ... 10 kHz (in 10 kHz
mode)
10 Hz ... 1 kHz
10 Hz ... 1 kHz
4-digit LC display, value last measured is displayed
selectable: metric or imperial
RS-232
3 x 1.5 V AAA batteries / LR03
battery life up to 5 hours at continuous operation
5 minutes after last keystroke
<2.1 V
-5 ... +55 °C; 0...95 % RH; non-condensing
150 x 77 x 40 mm
225 g (with batteries)
