Cover, O-ring cover, Interface gasket for Transmitter/Sensor, Interface gasket for Transmitter/Wall mounting
Safety symbols
DANGER
A0011189-EN
WARNING
A0011190-EN
CAUTION
A0011191-EN
NOTICE
A0011192-EN
Symbols for certain types of information
A0011182
A0011184
A0011193
1.
2. 3.
Cover connection compartment non Ex/Exde and cover connection compartment Exd
CAUTION
!
‣
The threads for the non Ex- and /Exde housing and the Exd housing are different in length. Take care to prefend those covers from
being confused!
Measuring unit mm (in)
A = Cover connection compartment non Ex/Exde
B = Cover connection compartment Exd
4
DANGER!
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury.
WARNING!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury.
CAUTION!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in minor or medium injury.
NOTICE!
This symbol contains information on procedures and other facts which do not result in personal injury.
Permitted
Procedures, processes or actions that are permitted.
Forbidden
Procedures, processes or actions that are forbidden.
Tip
Indicates additional information.
Series of steps
14 (0.6)
A
21 (0.8)
B
EA01143
A0031376
