Touratech 01-055-0082-0 Montage Seite 2

01-055-1082-0
Contains:
1 x Base plate VP45
2 x Side bag soft
1 x Tank bag
Installation:
These instructions are at our current level of knowledge. Technical issues subject to change. Legal requirements do not exist.
TOURING RALLYE RACING
Route the rear straps around motorcycle round frame
1.
tubes under the seat and attach them on the plastic
buckles. Photo 1
Route the front straps thru the inside of the fairing and
2.
around the side fairing on both sides and attach them on
the plastic buckles. Photo 2
3.
Attach the soft side bags on the base plate with zippers.
Remove the metal hooks on the straps (not used on
F650GS-models).
Attach the lower straps either on crashbars or route the left
side strap in front of the radiator and frame to the right
side attaching it on the right side buckle. Attach then the
right side strap on the left side buckle. Photo 3
Side bags can then be detached by the zippers and
pulled off from the front without releasing the straps from
left or right buckle.
TECHNOLOGY
Installation Instruction
Tank Bag Vp45 F650GS/Dakar
