Technical Description Mainboard Mainboard D2618...
Seite 2
For automatic driver updates, go to: "http://support.ts.fujitsu.com/support/index.html" Should you have any technical questions, please contact: ● our Hotline/Service Desk (see the Service Desk list or visit: "http://ts.fujitsu.com/support/servicedesk.html") ● your sales partner ● your sales outlet We hope you really enjoy using your new Fujitsu system.
Seite 4
Any liability that the data and illustrations are complete, actual or correct is excluded. Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which by third parties for their own purposes may infringe the rights of such owner. For further information see "http://ts.fujitsu.com/terms_of_use.html" Order No. Fujitsu Technology Solutions: A26361-D2618-Z210-2-8N19, Edition 2...
Seite 5
Mainboard D2618 Technical Description English Deutsch...
Mainboard D2618 English - 3 Overview Mainboard D2618 Channel C Module 0 2x PS2 FAN 3 FAN 4 PWR 2 PWR 1 Channel C Module 1 FAN 5 SYS 7 SPDIF Channel B Module 0 Channel B Module 1 Channel A Module 0...
Seite 10
Mainboard D2618 4 – English Fujitsu Technology Solutions...
English - 5 Mainboard D2618 Based on the Intel® X5520 chipset, the D2618 features some state-of-the-art technologies such as Dual-Core Xeon® Processor Series as well as Quad-Core Xeon® Processor Series support in LGA 1366 socket, multiple PCI-Express buses, triple channel DDR3 memory design, onboard PCIExpress Gigabit Ethernet, SATA ports, SAS ports, multiple USB 2.0 (Universal Serial Bus) and eSATA ports.
Mainboard D2618 6 – English Important notes With the mainboard installed you must open the system to access the mainboard. How to dismantle and reassemble the system is described in the operating manual accompanying the system. Connecting cables for peripherals must be adequately shielded to avoid interference.
Seite 13
Mainboard D2618 English - 7 Notice for the USA Compliance Information Statement (Declaration of Conformity Procedure) DoC FCC Part 15: This device complies with part 15 of the FCC Rules Operation is subject to the following conditions: This device may not cause harmful interference, and This device must accept any interference received including interference that may cause undesired operation.
Mainboard D2618 8 – English Hardware Specifications CPU – LGA1366 socket LAN – 10/100/1000 Ethernet Controller ● Two CPU-sockets ● WakeOnLAN by interesting packets, link status change and Magic-PacketTM ● Intel® Xeon Processors in the LGA1366 package: Nehalem EP 2S or ●...
Seite 15
Mainboard D2618 English - 9 Audio Advanced system monitoring and management ● Realtek ALC 663 ● Fujitsu System Management ● Host based Audio with 6-channel HD Audio ● Fujitsu Thermal Management ● Stereo Head-Phone Out ● Automatic system reset (ASR) ●...
Mainboard D2618 English - 11 System security features Basic security features For a complete description of the basic security features have a look at the BIOS Specification. Trusted Platform Module (TPM) Trusted Platform Modules are a Trusted Computing Group (TCG) security solution to increase the system security.
Mainboard D2618 12 – English SmartCase DynamicUSB This is hardware security circuit which will disable the USB-port if a USB-device is removed so no other USB-devices can be attached. Goal is that no data can be stolen by connecting i.e. a USB- stick.
6.4 GT/s. ● Single/Dual Processor System D2618 board supports one or two Dual-Core or Quad-Core or 6 core (only Cxx board version) Intel® Xeon® Processors. Single Processor System: When only installing a single processor on D2618, the processor must be installed in the CPU0 socket.
Mainboard D2618 14 – English BIOS POST-Codes (Port 80 status indicators) BIOS-POST codes are visible on the LCD-display (connected to the LCD-connector) or onboard via 8 yellow LEDs (L0-L7, L0 is the lowest bit, L7 the highest). Post-Code Overview: Standard system BIOS:...
Seite 21
Mainboard D2618 English - 15 POST Code Error Beeps Description Set segment register ES to 4GB access Enable A20 line 1-3-3-1 Autosize DRAM Initialize POST memory manager Clear 512KB base RAM Initialize CMOS emulation 1-3-4-1 RAM failure on address line xxxx...
Seite 22
Mainboard D2618 16 – English POST Code Error Beeps Description Set key click if enabled USB initialization Initialize 1394 devices 2-2-3-1 Test for unexpected interrupts Initialize POST display service Display prompt "Press F2 to Enter Setup" Disable CPU cache Test RAM between 512KB and 640KB...
Seite 23
Mainboard D2618 English - 17 POST Code Error Beeps Description Configure motherboard configurable devices(MCD) Initialize BIOS data area(BDA) Enable non-maskable interrupt(NMI) Initialize extended BIOS data area(EBDA) Test and initialize PS/2 mouse Initialize floppy controller Determine number of ATA drives Initialize hard disk controllers...
Seite 24
Mainboard D2618 18 – English POST Code Error Beeps Description Store CMOS emulation values to non-volatile area. One short beep before boot Terminate quiet boot Check password ACPI support Prepare boot Initialize DMI parameters Initialize PnP option ROMs Clear parity checkers...
Power Supply Considerations Power connectors D2618 is powered by a split plane PSU with six +12V-rails and 1000W continuous power. Four rails are for systemboard and two for peripherals (e.g. HHDs, graphics card). There are three power connectors on this motherboard as listed below.
Pin4: Fan PWM This 4-pin fan connector supports tachometer monitoring. There are five 4-pin fan connectors on D2618. Use these connectors to connect chassis and processor cooling fans to your motherboard. Cooling fans can keep the system stable and reliable for its product’s life.
Normally, a chassis has some control or signal wires can be connected onto a motherboard for hard drive LED, Power LED, power button, and reset button; The front panel connector has been implemented on D2618 for such purposes. PIN Signal...
Mainboard D2618 22 – English Communication connectors USB port (internal) – Internal/Front PIN Signal PIN Signal Pin 1 Pin 2 Not connected VCC AUX VCC AUX Data negative Port X Data negative Port X Data positive Port X Data positive Port X...
Mainboard D2618 English - 23 System monitoring and management connectors SCSI LED connector (Internal) PIN Signal Pin 1 Not connected SCSI-ON LED (low asserted input) SCSI-ON LED (low asserted input) Not connected Configuration jumper inside front panel Default Jumper position (Password Skip disabled and Recovery BIOS disabled)
Mainboard D2618 24 – English RTC – Reset and Clear CMOS jumper function description Signal RTC – Reset and Clear CMOS RTC is the on board inscription for that jumper and means RTC – Reset and Clear CMOS. RTC switch must not be in “on” state during normal operation.
Installing the Memory Before attempting to install any memory, make sure that the memory you have is compatible with the motherboard as well as the processor. The D2618 board supports up to twelve 240-pin 1.5 V 800/1066/1333 MHz DDR3 modules.
Mainboard D2618 26 – English Memory Installation Procedure When installing memory modules, make sure the modules align properly with the memory socket. There should be keys (small indents) on your memory modules that fit according to the keys in the memory socket.
Seite 33
Mainboard D2618 English - 27 Removing a memory module ► Push the clips on the right and left of the memory slot outward (1). ► Pull the memory module out of the memory slot (2). When installing memory, a module may require a considerable amount of force to seat properly, although this is very rare.
Installing the Processor and Heatsink The processor socket ist covered with a protective cap to protect the spring contacts In a warranty case the mainboard can only be taken back by Fujitsu Technology Solutions with the protective cap secured! Never touch the underside of the processor. Even minor soiling such as grease from the skin can impair the processor's operation or destroy the processor.
Seite 35
Mainboard D2618 English - 29 Hold the new processor between your thumb and index finger and insert it into the socket (b) so that the marking of the processor is aligned with the marking on the socket (a). ► Fold down the frame (1).
Mainboard D2618 30 – English Mounting heat sink Use only the heat sink supplied with your system! Be sure to use heat conducting material between the processor and the heat sink. If a heat conducting pad (rubber-like foil) is already applied to the heat sink, then use it. Otherwise you must apply a very thin layer of heat conducting paste.
Mainboard D2618 English - 31 Installing Add-In Cards Before installing add-in cards, please check if they are fully compatible with your motherboard. PCIe x16 PCIe x4/x8 PCIe x4/x8 PCIe x16 PCIe x4/x8 PCI 32 Simply find the appropriate slot for your add-in card and insert the card firmly. Do not force any addin cards (or anything else) into any slots if they won’t seat in place.
Mainboard D2618 32 – English Connecting External Devices Connecting external devices to the motherboard is an easy task. The standard devices you should expect to plug into the motherboard are keyboards, mouse, and printer cables. The following diagram will detail the ATX port stack for the following board:...
8-pin PWR2 power connector ● 10-pin PWR3 power connector D2618 is powered by a split plane PSU with six +12V-rails and 1000W continuous power. Four rails are for the systemboard and two for peripherals (e.g. HHDs, graphics card). The power supply has: ●...
Mainboard D2618 34 – English Replacing lithium battery In order to permanently save the system information, a lithium battery is installed to provide the CMOS-memory with a current. A corresponding error message notifies the user when the charge is too low or the battery is empty. The lithium battery must then be replaced.
English - 35 BIOS update When should a BIOS update be carried out? Fujitsu Technology Solutions makes new BIOS versions available to ensure compatibility to new operating systems, new software or new hardware. In addition, new BIOS functions can also be integrated.
Mainboard D2618 36 – English Glossary The technical terms and abbreviations given below represent only a selection of the full list of common technical terms and abbreviations. Not all technical terms and abbreviations listed here are valid for the described mainboard.
Seite 43
Mainboard D2618 Deutsch - Inhalt Übersicht über das Mainboard D2618 ....................2 Mainboard D2618..........................4 Handbuchkonventionen........................4 Wichtige Hinweise ..........................5 Allgemeine Informationen im Zusammenhang mit Boards............5 Hardware-Spezifikationen ........................7 Blockdiagramm............................. 9 Systemsicherheitsfunktionen......................10 Grundlegende Sicherheitsfunktionen ..................10 Trusted Platform Module (TPM) ....................10 SmartCase DynamicUSB ......................
Deutsch Mainboard D2618 2 – Übersicht über das Mainboard D2618 Channel C Module 0 2x PS2 FAN 3 FAN 4 PWR 2 PWR 1 Channel C Module 1 FAN 5 SYS 7 SPDIF Channel B Module 0 Channel B Module 1...
Seite 45
Mainboard D2618 Deutsch - Fujitsu Technology Solutions...
4 – Mainboard D2618 Basierend auf dem Intel® X5520 Chipsatz zeichnet sich das D2618 durch eine Reihe hochmoderner Technologien aus. Dazu zählen: Support für die Dual-Core Xeon® Prozessor-Serien sowie die Quad-Core Xeon® Prozessor-Serien im LGA 1366 Sockel, multiple PCI-Express Busse, Triple Channel DDR3 Speicherdesign, Onboard PCI-Express Gigabit Ethernet, SATA-Ports, SAS-Ports, multiple USB 2.0- (Universal Serial Bus) und eSATA-Ports.
Mainboard D2618 Deutsch - Wichtige Hinweise Zum Zugriff auf das installierte Mainboard muss das System geöffnet werden. Wie das System auseinandergebaut und wieder zusammengesetzt wird, ist im begleitenden Bedienerhandbuch beschrieben. Zur Vermeidung von Interferenzen müssen die Verbindungskabel für die Peripherie entsprechend abgeschirmt sein.
Seite 48
Deutsch Mainboard D2618 6 – Boards mit elektrostatisch empfindlichen Geräten (Electrostatic Sensitive Devices (ESD)) sind durch ein Etikett entsprechend gekennzeichnet. Bitte beachten Sie beim Umgang mit Boards, auf denen sich solche ESDs befinden, unbedingt Folgendes: ● Vor der Arbeit müssen Sie immer für eine statische Entladung (z. B. durch Berühren eines geerdeten Objekts) sorgen.
Deutsch Mainboard D2618 10 – Systemsicherheitsfunktionen Grundlegende Sicherheitsfunktionen Eine vollständige Beschreibung der grundlegenden Sicherheitsfunktionen ist in der BIOS- Spezifikation zu finden. Trusted Platform Module (TPM) Bei Trusted Platform Modules handelt es sich um eine Sicherheitslösung der Trusted Computing Group (TCG) zur Steigerung der Systemsicherheit. Das TPM befindet sich auf dem Motherboard und nutzt zur Kommunikation mit dem Rest der Plattform den LPC-Bus.
Mainboard D2618 Deutsch - SmartCase DynamicUSB Dies ist ein Hardware-Sicherheitsschaltkreis, durch den der USB-Port beim Entfernen eines USB- Geräts deaktiviert wird, so dass keine anderen USB-Geräte angeschlossen werden können. Auf diese Weise wird der Datendiebstahl durch Anschließen etwa eines USB-Sticks verhindert. Diese Funktion wird komplett über Hardware und BIOS realisiert.
Seite 54
Deutsch Mainboard D2618 12 – Folgende Geräteklassen werden innerhalb der USB-Spezifikation angegeben: Fett/kursiv dargestellte Klassen sind keine zulässigen USB-Geräte (wenn die Option SmartCase DynamicUSB aktiviert ist) – Ports, an denen während der BIOS-Nachphase solche Geräte angeschlossen sind, werden durch das BIOS deaktiviert.
Frequenz von bis zu 6,5 GT/s. ● Einzel-/Dualprozessorsystem Das D2618 unterstützt einen oder zwei Dual-Core oder Quad-Core oder 6 Core ( nur Cxxx Board-Version) für Intel® Xeon® Prozessor(en). Einzelprozessorsystem: Wenn nur ein Prozessor auf dem D2618 eingesetzt wird, muss dieser im Sockel CPU0 installiert werden.
Deutsch Mainboard D2618 14 – BIOS POST-Codes (Port 80-Statusanzeigen) BIOS-POST-Codes werden auf dem LCD-Display (angeschlossen an den LCD-Anschluss) oder onboard über 8 gelbe LEDs (L0 - L7, L0 ist niedrigste Bit, L7 das höchste) angezeigt. Übersicht über die Post-Codes: Standardsystem BIOS:...
Seite 57
Mainboard D2618 Deutsch - POST-Code Akustische Beschreibung Fehlersignale 8742-Tastatur-Controller testen ES des Segment-Registers auf 4 GB-Zugriff setzen A20-Leitung aktivieren 1-3-3-1 DRAM automatisch skalieren POST-Speicherverwaltung initialisieren 512 KB-Basis-RAM löschen CMOS-Emulation initialisieren 1-3-4-1 RAM-Fehler auf Adressleitung xxxx 1-3-4-3 RAM-Fehler bei Datenbits xxx des niedrigen Byte des...
Seite 58
Deutsch Mainboard D2618 16 – POST-Code Akustische Beschreibung Fehlersignale Boot-Abfolge vorab initialisieren EISA-Board initialisieren Tastatur testen Tastaturklick setzen, falls aktiviert USB-Initialisierung 1394-Geräte initialisieren 2-2-3-1 Test für unerwartete Interrupts durchführen POST-Anzeige-Service initialisieren Eingabeaufforderung "Press F2 to Enter Setup" anzeigen CPU-Cache deaktivieren...
Seite 60
Deutsch Mainboard D2618 18 – POST-Code Akustische Beschreibung Fehlersignale Setup aufrufen Boot-Markierung löschen Auf Fehler prüfen Support für RomPilot deaktivieren Booten des Betriebssystems vorbereiten (POST abgeschlossen) CMOS-Emulationswerte in nicht-flüchtigem Bereich speichern Ein kurzer Signalton vor dem Booten Quiet Boot beenden Kennwort überprüfen...
Seite 61
Mainboard D2618 Deutsch - POST-Code Akustische Beschreibung Fehlersignale BIOS-Stack und verschiedene Arbeitspuffer initialisieren Unbekannter Interrupt Speicherberichtschnittstelle initialisieren CPU-Marke/Hersteller bestimmen PCCards (CardBus,...) initialisieren Support für FirstWare ASF initialisieren IPMI initialisieren, 2. Teil PCIe-Geräte vorab initialisieren Support für FirstWave, 2. Teil Microcode-Update verifizieren Support für Remote Flash initialisieren...
Betrachtungen zur Stromversorgung Netzstecker Das D2618 wird über ein Split-Plane-Netzteil (PSU) mit sechs +12 V-Leitungen und 1000 W durchgängiger Leistung betrieben. Vier Leitungen sind für das System-Board und zwei für Peripheriegeräte (Festplatten, Grafikkarte) vorgesehen. Wie nachfolgend aufgelistet, sind auf dem Motherboard drei Netzstecker vorhanden.
Pin4: Fan PWM Dieser 4-polige Lüfteranschluss unterstützt die Geschwindigkeitsüberwachung Auf dem D2618 sind fünf 4-polige Lüfteranschlüsse implementiert. Über diese Anschlüsse können Lüfter zur Kühlung von Gehäuse und Prozessor mit dem Motherboard verbunden werden. Kühlende Lüfter tragen zur Systemstabilität und -zuverlässigkeit während der Lebensdauer des Produkts bei.
In der Regel verfügt ein Gehäuse über einige Kontroll- oder Signalkabel, die an ein Motherboard für die Festplatten-LED, Netz-LED, den Betriebsschalter und die Reset-Taste angeschlossen werden können. Für solche Zwecke wurde der Frontblendenanschluss auf dem D2618 implementiert. POL Signal POL Signal...
Mainboard D2618 Deutsch - Kommunikationsanschlüsse USB-Port (intern) – Intern/Vorderseite POL Signal POL Signal Pin 1 Pin 2 Nicht angeschlossen VCC AUX VCC AUX Data negative Port X Data negative Port X Data positive Port X Data positive Port X Nicht angeschlossen...
Deutsch Mainboard D2618 24 – Anschluss Benutzererfahrung Audio SPDIF OUT (intern) POL Signal Pin 1 SPDIF out Anschlüsse für Systemüberwachung und - verwaltung SCSI LED-Anschluss (Intern) POL Signal Pin 1 Nicht angeschlossen SCSI-ON LED (niedrig eingestellter Input) SCSI-ON LED (niedrig eingestellter Input)
Deutsch Mainboard D2618 26 – RTC – Reset and Clear CMOs- Beschreibung der Jumper-Funktion Signal RTC – Reset and Clear CMOS "RTC" ist die Onboard-Beschriftung für diesen Jumper. Die Bedeutung von RTC ist: Reset and Clear CMOS (Zurücksetzen und Löschen des CMOs).
Speicherinstallation Vor der Installation muss sichergestellt werden, dass der einzusetzende Speicher kompatibel mit dem Motherboard und dem Prozessor ist. Das D2618-Board unterstützt bis zu zwölf 240-polige, 1,5 V, 800/1066/1333 MHz DDR3-Module. Hier einige Kernpunkte, die Sie vor der Speicherinstallation auf dem D2618 beachten müssen:...
Deutsch Mainboard D2618 28 – Vorgehen bei der Speicherinstallation Bei der Installation von Speichermodulen müssen Sie darauf achten, dass die Module korrekt am Speichersockel ausgerichtet sind. Auf den Speichermodulen sollten sich kleine Kerben befinden, die zu den Kerben im Speichersockel passen. DDR-Module verfügen nur über eine Kerbe, die sich unmittelbar neben dem Mittelpunkt des Moduls/Sockels befindet.
Seite 71
Mainboard D2618 Deutsch - Entfernen eines Speichermoduls ► Die Klammern rechts und links am Speichersteckplatz nach außen drücken (1). ► Das Speichermodul aus dem Speichersteckplatz (2) ziehen. Mitunter kann schwierig sein, ein Modul in die korrekte Position zu bringen. Dies ist jedoch nur äußerst selten der Fall.
Installation von Prozessor und Wärmeableiter Prozessorinstallation Der Prozessorsockel ist zum Schutz der Federkontakte mit einer Schutzkappe versehen. In einem Garantiefall kann das Mainboard von Fujitsu Technology Solutions nur mit angebrachter Schutzkappe zurückgenommen werden! Niemals die Unterseite des Prozessors berühren. Selbst kleinste Verschmutzungen durch Hautfette können den Prozessorbetrieb beeinträchtigen oder zur Zerstörung des...
Seite 73
Mainboard D2618 Deutsch - Den neuen Prozessor zwischen Daumen und Zeigefinger halten und in den Sockel (b) einsetzen, so dass die Markierung auf dem Prozessor mit der Markierung auf dem Sockel (b) abschließt. ► Den Rahmen nach unten klappen (1).
Deutsch Mainboard D2618 32 – Montage des Wärmeableiters Verwenden Sie nur den zum Lieferumfang zählenden Wärmeableiter! Sorgen Sie dafür, dass zwischen Prozessor und Wärmeableiter wärmeleitendes Material verwendet wird. Wenn am Wärmeableiter bereits ein wärmeleitendes Polster (gummiartige Folie) angebracht ist, nutzen Sie dieses. Andernfalls muss eine sehr dünne Schicht wärmeleitender Paste aufgetragen werden.
Mainboard D2618 Deutsch - Installation von Add-In-Karten Prüfen Sie vor der Installation von Add-In-Karten, ob diese vollständig kompatibel mit dem Motherboard sind. PCIe x16 PCIe x4/x8 PCIe x4/x8 PCIe x16 PCIe x4/x8 PCI 32 Einfach den passenden Steckplatz für die Add-In-Karte suchen und die Karte fest einfügen. Wenn sich Add-In-Karten (oder andere Komponenten) nicht ordnungsgemäß...
Deutsch Mainboard D2618 34 – Anschließen von externen Geräten Das Anschließen von externen Geräten an das Motherboard ist eine einfache Aufgabe. Zu den Standardkomponenten, die üblicherweise an das Motherboard angeschlossen werden, zählen Tastatur-, Maus- und Druckerkabel. In nachstehendem Diagramm wird der ATX-Port-Stack für...
● 8-poliger PWR2-Netzanschluss ● 10-poliger PWR3-Netzanschluss Das D2618 wird über ein Split-Plane-Netzteil mit sechs +12 V-Leitungen und 1000 W durchgängiger Leistung betrieben. Vier Leitungen sind für das System-Board und zwei für Peripheriegeräte (Festplatten, Grafikkarte) vorgesehen. Das Netzteil verfügt über: ●...
Deutsch Mainboard D2618 36 – Austauschen des Lithium Akkus Der installierte Lithium Akku versorgt den CMOS-Speicher mit Strom, damit die Systeminformationen permanent gespeichert bleiben. Wenn der Akku leer oder fast leer ist, wird dem Benutzer eine entsprechende Fehlermeldung angezeigt. Der Lithium-Akku muss dann ausgetauscht werden.
Deutsch - BIOS-Update Wann sollte ein BIOS-Update durchgeführt werden? Fujitsu Technology Solutions stellt neue BIOS-Versionen zur Verfügung, um die Kompatibilität zu neuen Betriebssystemen, zu neuer Software oder zu neuer Hardware zu gewährleisten. Außerdem können neue BIOS-Funktionen integriert werden. Ein BIOS-Update sollte auch immer dann durchgeführt werden, wenn ein Problem besteht, das sich durch neue Treiber oder neue Software nicht beheben lässt.
Deutsch Mainboard D2618 38 – Glossar Die nachfolgend aufgelisteten Begriffe und Abkürzungen stellen nur eine Auswahl der kompletten Liste mit allgemeinen technischen Begriffen und Abkürzungen dar. Nicht alle hier aufgelisteten technischen Begriffe und Abkürzungen beziehen sich auf das hier beschriebene Motherboard.
