Mainboard Short Description Mainboard D2963...
Seite 2
For automatic driver updates, go to: "http://support.ts.fujitsu.com/de/support/index.html" Should you have any technical questions, please contact: • our Hotline/Service Desk (see the Service Desk list or visit: "http://ts.fujitsu.com/support/servicedesk.html") • Your sales partner • Your sales office We hope you really enjoy using your new Fujitsu system.
Seite 4
Any liability that the data and illustrations are complete, actual or correct is excluded. Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which by third parties for their own purposes may infringe the rights of such owner. For further information see "http://ts.fujitsu.com/terms_of_use.html" Order No. Fujitsu Technology Solutions GmbH: A26361-D2963-Z210-1-8N19, edition 1...
Seite 5
Dat a negati ve D Power LED GND Reserved (NC) Dat a positi ve C 10 = Not connected ResetSwitch GND 10 = (KEY) FANLESS SILENT DRI VES M UL TI BOOT RECOVERY BI O S A26361-D2963-Z240-1-8N19 Fujitsu Technology Solutions...
Seite 6
- / - / - Temp monitored CPU / ONB1 / ONB2 / HDD - / - / - / - Fujitsu Technology Solutions Keyboard Power Button Support Special Features Silent Fan / Silent Fan LT / System Guard / Silent Drives...
Seite 7
- / - LAN (RJ-45) PS/2 Mouse / Keyboard 1 / 1 USB (2.0, ~40MB/s) 2 (only D2963-A) Serial (RS232, FIFO, 16550 compatible) 1 (only D2963-B) DC-IN (external input) 20 V / 3.5 A 1) Via optional DVI-I / VGA interface connector...
Seite 8
24/ 7 Operating Mo de EXTENDED TE M PERATURE SILE N T FAN SYSTE M GUARD FANLESS SILENT DRI M UL TI BOOT HDD PASSWO RD RECOVERY B I O S DESK UPDATE W ATCH DOG A26361-D2963-Z241-1-8N19 Fujitsu Technology Solutions...
Seite 9
- / - External Connectors VGA Sub D / DVI-I / HDMI - / 1 / - Audio In / Line Out (or driver configuration) 1 / 1 S/PDIF (digital Audio) OUT / IN - / - Fujitsu Technology Solutions...
Seite 10
3) CPU fan = 4 pin PWM, system fan = 4 pin PWM or 3 pin (selectable via BIOS Setup) Power Supply Requirements - for onboard components (worst case) Mainboard current Voltage Source Maximal variation Typical Main Power Supply 19V - 24V +10% / -15% Fujitsu Technology Solutions...
Seite 11
Mainboard D2963 First-time setup Deutsch English...
Die Position der Anschlüsse und Steckverbinder Ihres Mainboards finden Sie am Anfang des Handbuches. Die markierten Komponenten und Steckverbinder müssen nicht auf dem Mainboard vorhanden sein. Externe Anschlüsse Die Position der externen Anschlüsse Ihres Mainboards finden Sie am Anfang des Handbuches. Fujitsu Technology Solutions...
Technische Daten Technologie DDR2 667 / DDR2 800 SDRAM (SO-DIMM) Gesamtgröße 1 und 2 GByte (D2963-A/B) 1, 2 und 4 GByte (D2963-S) Modulgröße 1, 2 oder 4 GByte pro Modul Es dürfen nur ungepufferte 1,8 V-Speichermodule ohne ECC verwendet werden.
Deutsch - 5 BIOS Update Wann sollte ein BIOS-Update durchgeführt werden? Fujitsu Technology Solutions stellt neue BIOS-Versionen zur Verfügung, um die Kompatibilität zu neuen Betriebssystemen, zu neuer Software oder zu neuer Hardware zu gewährleisten. Außerdem können neue BIOS-Funktionen integriert werden.
Seite 18
6 - Deutsch BIOS Update Fujitsu Technology Solutions...
Seite 19
Mainboard D2963 First-time setup Deutsch English...
Seite 21
BIOS update using a USB stick ............Fujitsu Technology Solutions...
The location of the ports and connectors of your mainboard is specified at the beginning of the manual. The components and connectors marked are not necessarily present on the mainboard. External ports The location of the external ports of your mainboard is specified at the beginning of the manual. Fujitsu Technology Solutions...
Technology DDR2 667 / DDR2 800 SDRAM (SO-DIMM) Total size 1 and 2 Gbyte (D2963-A/B)1, 2 and 4 Gbyte (D2963-S) Module size 1, 2 or 4 Gbyte for one module You may use only unbuffered 1.8 V memory modules without ECC.
BIOS Update When should a BIOS update be performed? Fujitsu Technology Solutions makes new BIOS versions available to ensure compatibility with new operating systems, new software or new hardware. In addition, new BIOS functions can be integrated. A BIOS update should also always be performed if there is a problem that cannot be solved using new drivers or new software.
