Introduction
Dear Customer
Our machines are mature products of verifiable
reliability. We are able to supply them, therefore,
with a one year warranty.
First check for any signs for transit damage. If you
discover any damage, please report it at once to the
carrier in question.
1. Technical data
Drilling capacity
Drilling depth
Scroll chuck
Spindle taper
Reach
Pillar diameter
Table
Table adjustment
Table angle adjustment
Useful area/base plate
Motor speed
Motor rating
Speed
Electrical features
Standing area
Overall dimensions
Weight
Packed dimensions
Sound pressure level measured at the operator's ear
in accordance with DIN 45635
at maximum speed in idle mode
2. Product liability / Warranty
All work and uses which are not listed require written
approval from Einhell.
To maintain your rights under the warranty and in the
interest of product safety, please observe the safety
regulations.
If you wish to assert any warranty claims, contact
your dealer.
13.11.2001 14:03 Uhr
16 mm diameter
76 mm
3-16 mm diameter/B 16
MK 2
138 mm
65 mm
260 mm diameter
infinitely variable
90/0/90
degrees infinitely variable
215 x 200 mm
1400 rpm
550 watts
350/630/1020/1585/2500 rpm
no-volt tripping
360 x 230 mm
910 x 515 x 320 mm
42 kg
780 x 440 x 280 mm
80 dB/A
Seite 7
Warranty repairs are always carried out by us or by
Einhell-authorized service centres. When the
warranty period is over, repairs may also be carried
out by other suitably specialized companies.
3. Items supplied
SB 701
Scroll chuck of diameter 3-16 mm/B 16
Chuck key
Shank MK 2/B 16
Knock-out wedge
Setting tool
Hinged chip guard
4. Proper use
The SB 701 is a pillar drill with V-belt drive for
five different speed settings. Holes of up to 16
mm diameter can be drilled in vertical direction.
To use the pillar drill properly you must observe
the operating, maintenance and repair
instructions as well as the safety regulations
found in this manual.
The SB 701 is to be used only by persons who
are acquainted with the machine. All the
pertinent accident prevention regulations are to
be observed.
Unauthorized modifications to the machine
release the manufacturer from all liability for any
damage caused as the result.
For design reasons it is impossible to eliminate
all residual risks, namely:
1. Reaching into the chuck and drill when in use
2. Cutting yourself on sharp drill bits
3. Chips flung out during drilling
4. Clothes and similar caught in the machine
5. Safety regulations
Pull out the power plug before carrying out any
maintenance or making any adjustments
Protect the machine from the wet and damp
Check whether all the safety devices are properly
fitted
Do not remove any mechanical or electrical
safety devices
Wear safety items when drilling.
Always keep long hair suitably covered.
Caution! Long hair gets caught easily in
rotating tools.
Always clamp workpieces with suitable additional
tools.
Always secure large parts against revolving with
the bit.
