GB
Keep the noise emissions and vibrations to a
minimum.
Only use appliances which are in perfect working
order.
Service and clean the appliance regularly.
Adapt your working style to suit the appliance.
Do not overload the appliance.
Have the appliance serviced whenever
necessary.
Switch the appliance off when it is not in use.
Wear protective gloves.

5. Before starting the equipment

Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
5.1 Fitting the additional handle (Fig. 2)
The angle grinder must not be used without the
additional handle (6).
The additional handle can be secured in any of 3
positions (A, B, C).
Tool side Suitable for
Left (position A) Right-handed users
Right (position B) Left-handed users
Top (position C) Using cutting wheels
5.2 Adjusting and changing the safety device
(Fig. 3)
Pull out the power plug.
Switch off the tool. Pull the power plug.
Adjust the guard (7) to protect your hands so that
the material being ground is directed away from
your body.
The position of the guard (7) can be adjusted to
any specific working conditions. Undo the clamp
handle (a) and turn the cover (7) into the
required position.
Ensure that the guard (7) correctly covers the
gear wheel casing.
Secure the clamp handle (a) again.
Ensure that the guard (7) is secure.
To remove the safety device, open the clamp
lever (a) and turn the safety device until it can be
taken off.
To attach the safety device, proceed in reverse
order with instructions for removing the safety
device.
12
24.08.2009 8:28 Uhr Seite 12
Take care that the safety device is secure.
Never use the angle grinder without the
guard.
5.3 TEST RUN FOR NEW GRINDING WHEELS
Allow the right-angle grinder to run in idle for at least
1 minute with the grinding or cutting wheel fitted in
place. Vibrating wheels are to be replaced
immediately.

6. Operation

6.1 Switch (Fig. 4)
To switch on:
Push the locking button (4) towards the rear and at
the same time, press the ON/OFF switch (3).
To switch off:
Release the locking button and ON/OFF switch
Wait until the machine has reached its top
speed. You can then position the angle grinder
on the workpiece and machine it.
6.2 Changing the grinding wheels (Fig. 5)
Use the face spanner (8) supplied to change the
grinding wheels.
Pull out the power plug.
Simple wheel change by spindle lock:
Press the spindle lock and allow the grinding
wheel to latch in place.
Open the flange nut with the face spanner.
(Fig. 5)
Change the grinding or cutting wheel and tighten
the flange nut with the face spanner.
Important!
Only ever press the spindle lock when the motor
and grinding spindle are at a standstill!
You must keep the spindle lock pressed while
you change the wheel!
For grinding or cutting wheels up to approx. 3 mm
thick, screw on the flange nut with the flat side facing
the grinding or cutting wheel.
