ZE-MU620IR
Thank you for your purchase of this ZENEC product!
With the ZE-MU620IR monitor, you have chosen a technically mature high quality product
that will give you a long service life and very high reliability, since this product has been
assembled using only high quality parts.
Even though this unit has been designed for intuitive and easy operation, it is recommended
that you read this manual, learning how to operate this device in detail, so you are able to
use all implemented features and functions. Please retain this operating manual in a safe
place after reading it, for future reference.
Read the warranty conditions at the end of this manual, to make sure you benefit from full
warranty coverage.
If you have further questions about this product, please consult the dealer where it was
purchased, or the ZENEC distributor in your country.

TECHNICAL FEATURES

■ 6.2"/16:9 aspect ratio TFT-LCD panel of high brightness
■ TFT-LCD panel with 137.5 x 77.2 mm active display area and 1440 x 234 pixels
panel resolution with a total count of 336'960 dots
■ Large viewing angle left/right > 60° / top > 60° / down > 30°
■ Compact and shallow housing design
■ Multi-norm system with PAL/NTSC auto switching
■ Setup and picture adjustment by on-screen display menu
■ Integrated 2-CH IR-transmitter to operate wireless IR-headphones
■ A/V extension cord with multiconnector for power supply and A/V-inputs
■ 2 x A/V-inputs
■ IR-remote control

SPECIAL FEATURES

6.2"/16:9 High Density Display:
The ZE-MU620IR is a TFT-LCD active matrix 16:9 video monitor, featuring a 6.2" high quality
color LCD screen. It deploys a color TFT-LCD panel with 336'960 dots resolution, to give
you excellent picture details.
Compatibility:
The monitor is compatible with PAL and NTSC video streams – the internal video signal
processing electronics automatically synchronize with PAL or NTSC video signals.
Applications:
The ZE-MU620IR will work with any common video source unit, featuring an RCA composite
video output, such as DVD-players or DVB-T resp. TV-tuners.
