AUDIO INPUT [ANALOG IN]
By default the signal coming from the [ANALOG IN] connector, before being transmitted back to the [LEFT],
[RIGHT], [ROTARY SPEAKER] and [PHONES] outputs, is sent to the effects chain (Reverb, Drive, Rotary and
Equalizer). If you do not want this signal to be processed by such effects, while holding down the
[TRANSPOSE SELECT] button, press the B3 key of the upper manual.
To restore the default audio path, while holding down [TRANSPOSE SELECT], press the C4 key of the upper
manual.

6.9 PANIC FUNCTION

The Panic function allows you to instantly silence all the notes that are currently playing. This function is to be
used if, due to reasons unrelated to the instrument (mainly electrical disturbances or duplicated notes from
MIDI IN), it is no longer possible to turn off one or more notes. To recall this function, while pushing the
[TRANSPOSE SELECT] button, press the C6 key on the upper manual.

6.10 CANCEL FUNCTION

The C key on the Black Octave in
[DRAWBARS SET B] in
which it is possible to disable the internal sound generation and allowing you to use the instrument as a master
keyboard. In this mode, the keyboard is sensitive to the strenght applied to the keys, so that notes transmitted
by the [MIDI OUT 1] and [MIDI OUT 2] ports will have variable velocity.

6.11 LAYER FUNCTION

In order to send out notes with variable velocity through the [MIDI OUT 1] and [MIDI OUT 2] ports while at the
same time playing with the internal sound generation (that is, without enabling the Cancel function described in
chap.6.10), activate the Layer function. To do so, press and hold the [TRANSPOSE SELECT] button and press
one of these four keys: D#3 to activate the function on the lower manual; C#3 to deactivate it on the lower
manual; E3 to activate the function on the upper manual; D3 to disable the function on the upper manual.
NB
In Layer mode you will have notes that will start playing on the second contact of the keyboard keys (so slightly later).

6.12 FACTORY RESET

This function allows you to reset the Presets, the initial panel status (if modified through the procedure
described at the beginning of chapter 4) and the functions recalled through the upper manual (see chap.7.1),
any parameters modified with
To carry out the Factory Reset in
buttons [TRANSPOSE SELECT], [ROTARY DIRECT] and [ROTARY CLASSIC/ROCK], then release them after
all the leds of the side panels have blinked four times.
To carry out the Factory Reset in
SELECT], [UPPER PRESETS 1] and [UPPER PRESETS 2], then release them after all the leds of the side panels
have blinked four times.
NB
When a factory reset is performed, all changes made by the user will be irreparably lost.
Legend
and
Legend Live
, recall the Cancel function, i.e. the Local Off of the instrument, through
Legend Editor
, to the standard factory settings.
Legend Legend Classic,
and
Legend Live,
Legend Classic
or pressing [DRAWBARS SET A] and
switch on the instrument while pressing the
switch on the instrument while pressing [TRANSPOSE
