Terminal Function
1.1 Shared connection (common) relay output
1,2,3
1.2 Digital output 1
1.3 RS485 bus, cable A
1.4 Supply voltage, +24 V
1.5 Relay output 1
1.6 Digital output 2
1.7 RS485 bus, cable B
1.8 Supply voltage, ground (GND), ground
reference for all inputs
2.1 Relay output 2
2.2 Digital output 3
2.3 Digital input I7
2.4 Analogue input I1
2.5 Relay output 3
2.6 Digital output 4
2.7 Digital input I8
2.8 Analogue input I2
3.1 Relay output 4
3.2 Digital output 5
3.3 Digital input I9
3.4 Analogue input I3
3.5 Relay output 5
3.6 Digital output 6
Installation
