Tableau 1 : Roues - Bcs 710 Wartungsanleitung

3.50-8
MACCHINA
MACHINE
D = 395mm(15,5")
MACHINE
L = 97mm (3,8")
MAQUINA
C = 2.50-8
MASCHINE
bar = 1,2/1,5
710
710G
S = 425mm
712
718
720
722
732
730
TABELLA 1 – TABLE 1 – TABLEAU 1 – TABLA 1 – TAFEL 1
4.00-8
D = 427mm(17") D = 463mm(18")
L = 108mm (4,3") L = 114mm (4,5")
C = 2.50-8 C = 3.50-10
H = 10kg (lbs22) H = 15kg (lbs33)
bar = 1,2/1,5 bar = 1,2/1,5
S = 435mm
S = 435mm S = 538mm
S = 436mm S = 539mm
4.0-10 5.0-10
D = 512mm(20")
L = 140mm (5,5")
C = 3.50-10
H = 15kg (lbs33)
bar = 1,2/1,5
33
5.00-12
D = 570mm(22,5")
L = 130mm (5,2")
C = 5jA-12
H = 34kg (lbs75)
bar = 1,2/1,5
F:D = 430mm(17")
S = 765mm
L = 100mm(4")
F:D = 430mm(17")
S = 766mm
L = 100mm(4")
