Shield Protective shroud
AUTOMATIC TORCH SETUP (REF. 040014)
1 - CHOICE OF CONSUMABLES
The auto torch uses «unprotected» consumables, a small distance distance (2 to 3 mm, between the torch and the metal).
To maximise the cutting performance, it is important to use the correct consumables depending on the plasma cutter settings.
• A current that is too low leads to low cutting performance.
• A current that is too high for the tailpipe leads to early deterioration.
Gouging is impossible with an automatic torch.
Auto torch consumables:
PRECISION CUT
037496 (x1)
45A
039216 (x1)
039292 (x1)
039339 (x1)
De ector
039223 (x1)
039308 (x1)
039445 (x1)
De ector
PLASMA CUTTER 85A / 125A
Tailpipe
039315 (x5)
45A
039162 (x5)
45A
039179 (x5)
65A
ohmic
039186 (x5)
85A
Protective
shroud
Tailpipe
039193 (x5)
105A
039209 (x5)
125A
ohmic
Tailpipe
Protective
shroud
Electrode Diffuser
039155 (x5) 039131 (x1)
Electrode Di user
039155 (x5) 039148 (x1)
Electrode Di user
EN
Torch
85A TRI
038479 - 6 m
039520 - 12 m
125A TRI
038479 - 6 m
039520 - 12 m
25
