d. Four Channel Remote Control Transmitter
Included in the scope of delivery is a remote control
transmitter with two remote control levers, which are assigned
the two respective functions.
These functions are activated by the movements forwards /
backwards and right / left.
AA X 8 batteries are required for the
transmitter (not included)
Trim lever pitch
Pitch (Lift)
Tail (Rudder)
Trim lever tail
Transmitter crystal
Functions on the back of the transmitter:
• Charging socket
• Battery chamber
Put the charged batteries in the battery compartment of the
transmitter.
Pay attention to the correct polarity!
Telescopic antenna
1 Reverse switch for roll
Servo reverse switches to change the reaction
direction.
CARSON UL-Copter C35 50 050 7029
Trim lever nick
Nick (Elevators)
Roll (Ailerons)
Trim lever roll
ON/OFF switch
4 Reverse switch for tail rotor function
3 Reverse switch for acceleration
2 Reverse switch for pitch
