Steering the quadrocopter

You have different steering options:
• Upwards/downwards
Move the throttle (2a) upwards/downwards
(figure H).
• Sideways (left/right)
Move the joystick (2d) to the left/to the right
(figure I)
• Forwards/backwards
Move the joystick (2d) forwards/backwards
(figure J).
• Turning (left/right)
Move the throttle (2a) to the left/to the right
(figure K).
360° rollover (figure L)
1. Steer the quadrocopter (1) to a height of
approx. 2-3m.
2. Keep it hovering and push the joystick (2d)
downwards. A signal tone will sound.
3. Move the joystick (2d) in a flying direction. The
quadrocopter will perform a 360° rollover in
the selected direction.
Note: You need sufficient room height for a
360° rollover.

Calibration (figure M)

It is possible that the quadrocopter may fly in an
uncontrolled manner and needs to be calibrated.
Proceed as follows:
1. Place the quadrocopter (1) on a level,
horizontal surface.
2. Simultaneously push the throttle (2a)
downwards and to the left and the joystick (2d)
downwards and to the right. The control lamps
(1c) on the quadrocopter will flash for approx.
3 seconds. As soon as the control lamps light
constantly the calibration is complete and the
quadrocopter is ready to fly.
Note: Repeat the calibration if the quadrocopter
still flies in one direction in an uncontrolled
manner.

Cleaning, repair, and storage

The quadrocopter must always be kept dry and
must be freed of any soiling such as wool threads,
hairs, dust, etc. after every flight.
14 GB
Downloaded from www.Manualslib.com manuals search engine
Use a dry cloth to clean the article and avoid
contact of the electronics, storage battery, and
motors with water.
Store the quadrocopter in a dry and dust-free
place out of direct sunlight. Disconnect the
storage battery plug connector (1d) from the
quadrocopter plug connector (1e) and the
charger cable (4). Remove the batteries (3) from
the remote control.

Replace the rotor blades

Replace the rotor blades (1a) as soon as they are
damaged.
Note: If the rotor blades are damaged there
is a risk that sections of material will separate
during use and lead to damage or risks to
the surroundings. There are two different rotor
blades distinguished by markings A and B on the
underside. The markings must correspond to the
markings on the quadrocopter (figure E).
Proceed as follows to change the rotor blades
(1a):
1. Place the tool (5) under the rotor blade (1a)
that you wish to replace and lever it off the
quadrocopter (1).
2. Place the new rotor blade (6) at the position
where the damage rotor blade (1a) was
previously.
Note: Please ensure that the new rotor blade (6)
is approximately 0.5mm away from the motor
casing on the quadrocopter.
Attention! Always place a rotor blade
marked A on the rotor arms marked A.
Place rotor blades marked B on rotor
arms marked B.

Notes on disposal

Dispose of the article and the
packaging materials in accordance
with corresponding, local regulations.
Packaging materials such as foil bags
must be kept away from children. Keep
the packaging material out of the reach
of children.
Devices that are marked with this symbol
should not be disposed of as domestic
waste. You are obliged to dispose of these
