Status LED flashes alternately Red and White or Red and Blue at intervals of two and a half
seconds (depending on the connection status of the backhand scanner):
The battery charge state is critical.
•
Status LED lights Green once and vibration motor vibrates briefly:
A barcode was successfully read and transmitted via Bluetooth.
•
Status LED lights up Red once:
A barcode was successfully read, but there is no Bluetooth connection. The data that was read in is
discarded.
•
Status LED lights up Yellow once:
A configuration barcode was read successfully. The settings are applied and the backhand scanner
is restarted.
17.2 2D scanner
A 2D scanner is integrated into the backhand scanner.
The table below contains the typical read distances of the 2D scanner:
Barcode size
4 mil code 39
5 mil code 128
5 mil code 39
5 mil PDF417
10 mil DataMatrix
100% UPCA
20 mil code 39
* Not specified, as the minimum distances depend greatly on the width of the barcode and scanning angle.
When the red scanner light is illuminated, a scan is being triggered. If no barcode can be detected, the
scanner light goes out again after two seconds without the status LED of the backhand scanner having
changed.
The scanner is optionally available with the ability to read DotCodes.

17.3 Proximity sensor

A scan can be triggered via the proximity sensor. A scan is triggered as soon as the configured distance to
an object is undershot. The distance at which a scan is triggered can be configured via barcode (see section
7 Configuration)

17.4 NFC

An NFC tag containing the BT-MAC address is integrated into the backhand scanner. This allows a BT-
compatible device to establish a connection to the backhand scanner.

17.5 BT-compatible short-range radio

A BT-compatible short-range radio according to BT Standard V4.0 is integrated into the backhand scanner.
Hasci_Set_Kurzübersicht_Brief Overview_V1.00_de_en
Min. distance
approx. 8.4 cm
approx. 7.1 cm
approx. 5.1 cm
approx. 7.9 cm
approx. 7.4 cm
*
*
Max. distance
approx. 22.4 cm
approx. 20.8 cm
approx. 34.3 cm
approx. 21.3 cm
approx. 25.7 cm
approx. 66.0 cm
approx. 76.2 cm
