19.2.6 Suffix

Standard (without suffix)
)]{FEFEFEFEFEFEFE00FE

20 Technical Data

20.1 Backhand scanner

The table below includes the technical data for the Hasci backhand scanner.
Housing
Protection class
Operating
temperature
Charging
temperature
Storage temperature
Rel. humidity
Device dimensions
Weight
Power supply
Keyboard/keys
Barcode scanner
Distance sensor
Interfaces
On request
Accessories

20.2 Docking station

The table below includes the technical data for the DSHasci docking station.
Housing
Protection class
Operating
temperature
Storage temperature
Device dimensions
Weight
Power supply
Display
Interfaces
Hasci_Set_Kurzübersicht_Brief Overview_V1.00_de_en
ABS
IP54
-20 °C to 50°C/-4 °F to 122 °F
10 °C to 25 °C/50 °F to 77 °F
-20 °C to 20 °C/-4 °F to 68 °F
5 % - 90 % non-condensing
approx. 56 x 45 x 14 mm (L x W x H)
approx. 45 g
Lithium-polymer battery with 1.66 Wh (450 mAh/3.7 V)
Button for switching on/off and for scanning
2D scanner integrated into the housing (SE4710)
Infrared proximity sensor
BT-compatible short-range radio,
vibration motor,
NFC
Other mounting options
DSHasci docking station
Hasci zipper,
ACD hand strap
ABS V0 side parts; ABS/FDA charging cradle
IP30
10 °C to 40 °C/50 °F to 104 °F
-20 °C to 60 °C/-4 °F to 140 °F
approx. 138 x 80 x 138 mm (L x W x H)
approx. 127 g
15 V DC, 36 W
2 status LEDs
DC connector
CR (Carriage Return)
)]{FEFEFEFEFEFEFE0DFE
