19 Configuration

19.1 Individual configurations

The behavior of the backhand scanner can be adjusted by means of certain barcodes called configuration
barcodes.
One parameter to be set is the trigger radius of the proximity sensor within which the scanner is triggered as
soon as an object enters it. In addition, the suspend time can be set, the vibration motor can be
(de)activated, the keyboard type can be configured to insert characters via BLE, a possible keyboard symbol
can be set at the end of each transmitted barcode and all system settings can be reset.
Section "Standard configurations" shows example barcodes that can be set quickly and easily for setting
possible example variables. To change several different system parameters, scan the corresponding
barcodes one after the other. Only the barcode for "Reset to default values" causes all stored variables to be
reset.
The structure of the configuration barcode is shown below so that each system variable can be set
individually in a barcode.
Configuration codes themselves must have a length of exactly 21 ASCII characters and the following
sequence of brackets at the beginning: )]{
If a system variable should not set, this is indicated by the character string FE in the barcode.
The parameters are stored in the barcode as follows:
Place in bar code:
1
2
3
4 + 5
6 + 7
8 + 9
10 + 11
12 +13
14 + 15
16 + 17
18 + 19
20 + 21
___________________________
* Registered trademark – Android
Hasci_Set_Kurzübersicht_Brief Overview_V1.00_de_en
System variable:
First prefix character
Second prefix character
Third prefix character
Proximity sensor
parameters 1
Proximity sensor
parameters 2
Proximity sensor
parameters 3
Proximity sensor
parameters 4
Suspend time
Vibration motor
Keyboard type for BLE
character insertion
Keyboard symbol after
barcode transmission
Reset to factory settings
TM
– Android is a trademark of Google LLC
Default value: Description:
) Cannot be changed!
] Cannot be changed!
{ Cannot be changed!
00 For more information please
contact Support
40 For more information please
contact Support
00 For more information please
contact Support
03 For more information please
contact Support
40 2) see following page
01 01: Vibration motor is activated
00: Vibration motor is deactivated
02 Keyboard type
00: Windows
01: Windows
02: Android
03: Android
00 All displayable ASCII characters (in
hexadecimal format)
00: No additional character
0D: Carriage Return
2C: Comma
3B: Semicolon
...see ASCII table
FE FE: No system reset
Other value: System is set to
factory settings
®
