Legend of the circuit schematic

S1 On/Off switch for navigation instruments
S2 On/Off switch for instrument lighting
F1 Fuse for navigation instruments (5 A)
F2 Fuse for instrument lighting (5 A)
Recommended cable section: 1.5 mm

Cable lengths

Compass sensor - indicating instrument
Indicating instrument - second instrument 10 m max.
Second instrument - third instrument

Technical data

Measuring principle:
Accuracy:
Application:
Max. inclination angle: in pitch and roll direction: + 30°
Supply voltage:
Current consumption:
Operating temperature: -10 to + 60 oC
Type of protection:
EMC protection:
Dimensions:
40
INSTALLATION / DATA
2
Fluxgate magnetic field measurement
liquid-damped coils
+ 3° after compensation
Field strength: 8 to 50 A/m
10.8 to 32 V DC
Indicating instrument:
about 90 mA at 12 V DC without lighting
about 250 mA with lighting
Sensor:
about 50 mA at 12 V DC
Indicating instrument: DIN 40050 - IP 65 at front
Compass sensor: DIN 40050 - IP 65
CE: EN 50081-1, EN 50082-1
Indicating instrument:
Front ring dia.:
Installation dia.:
Installation depth (with union nut): 56 mm
Installation depth (with bracket):
Compass sensor: See figure page 37
Technical modifications reserved.
20 m max.
10 m max.
105 mm
86 mm
90 mm
