1:1/10:1 Probe RT-ZP03
Electrical specifications
Attenuation ratio:
Bandwidth:
Rise time:
Input impedance:
Input voltage:
Miscellaneous
Temperature range:
Relative humidity:
Altitude:
Polution degree:
Cable length:
Derating
Included in delivery
1
3
10
Downloaded from www.Manualslib.com
1:1
10 MHz (–3 dB), typ.
35 ns, typ.
1 MΩ II 82 pF
max . 55 V
0 - 40 °C
max . 80%, without condensation
max . 2000 m
2
ca . 1 .20 m
8
5
9
4
manuals search engine
10 : 1
300 MHz (–3 dB), typ.
1 .15 ns, typ.
10 MΩ II 12 pF
max . 400 V
RMS
RMS
Note that the input impedance of the probe
decreases as the frequency of the applied sig-
nal increases.
Fig. 1: Derating curve
6
(600 V transient overvoltage)
1 Probe
2 Ground lead
7
3 Retractable hook
4 Adjustment tool
5 Protection cap
6 Identification tags
7 IC Insulating cap
8 Additional probe tip
9 Ground clip
2
Fig. 2: Parts included in delivery
