2. Introducing the Appliance

1
2
3
4
5
6
8
19
1. Steam relief valve cover
2. Steam relief valve frame
3. Steam relief valve
4. Electromagnetic valve
5. Cover lock
6. Cover opening/closing latch
7. Control panel
8. LED Display
9. Removable condensate chamber
10.Appliance cover
11. Cover lock ring
12.Inner Cover Holder
13.Gasket
14.Temperature sensor
15. Removable inner cover
16.Inner cover retention seal
17. Base
18. Cable input/power cable
10
11
9 15
16
7
20
21
160
120
29
12
13
14
18
17
22 23
