Product Description - Concept CA3000 Bedienungsanleitung

EN

PRODUCT DESCRIPTION

1. Front cover
2. Air inlet (on both sides)
3. Control panel and display screen
4. Air outlet
5. Air quality indicator
6. Handle
7. Water tank
8. Display screen
9. Control panel
4
3
5
9
76
5
6
2
7
8 9
CA3000
PROPERTIES
Pre-filter (Fig. 1)
Primary filtration uses an aluminium alloy filter located in the pre-filter. It is mainly used to
filter dust larger than 5 microns, including large dust particles, grease, pollen, flying residues
1
and other pollutants. It can be washed many times and reused.
Cold Catalyst filter (Fig. 2)
• The catalytic decomposition reaction of a cold catalyst does not require UV radiation, high
temperature or high pressure. In a normal environment, the catalytic effect can play a role
in controlling air pollution.
• The main components of the cold catalyst come from additives found in food and
pharmaceuticals. It is non-toxic, non-corrosive and non-flammable. Under normal
temperature conditions, the catalytic reaction can remove formaldehyde, benzene, xylene,
TVOC and other harmful gases. The reaction produces water and carbon dioxide. It does not
cause any secondary pollution. It is a safe and ecological product of the highest standard,
suitable for a healthy home.
• During the catalytic reaction, the cold catalyst is not directly involved in the reaction. The
cold catalyst does not change or disappear. For this reason, the filter will be effective for
more than five years without external damage. It basically synchronizes with the long-term
release of formaldehyde.
2
Activated carbon filter (Fig. 2)
Activated carbon contains highly effective additives. It has good absorption and collection
properties.
Antibacterial cotton filter (Fig. 3)
The antibacterial filter is a precision filter to trap particles with a diameter of 5 microns. At the
same time, an antibacterial agent is added to the filter which can effectively kill more than
99 % of any bacteria in the air.
Highly efficient HEPA filter (Fig. 3)
An efficient HEPA filter filters over 99 % of airborne bacteria, smoke and dust particles of
0.3 microns. In combination with a multifunction filter, the HEPA filter can filter out microscopic
particles over 20 nanometres in diameter, including bacterial fungi, dust, allergens and some
viruses, while filtering out smoke. According to the World Health Organization, the bird flu
virus, the flu virus and Legionella bacteria are larger than 20 nanometres. The HEPA filter can
filter out these bacteria.
UV sterilization light
UV sterilization can kill various bacteria in the air using 365 nanometre UV wavelength. The UV disinfection lamp is
usually used to disinfect air, surface and water. It is able to purify the air, remove stale odours and create a certain
amount of anions. This makes the air fresh and prevents the spread of viruses in the air or on surfaces.
Anionic cleaner
It releases large amounts of anions into the air, which the oxygen molecules then add to their outer shell to obtain
a negative charge. It has an extraordinary ability to combine with positively charged flying dust, smoke, bacteria and
viruses inside buildings. As a result, the free-flowing waste will fall, thus cleansing the air and the environment without
harming humans. These ultra fine particles are difficult to filter by conventional mechanical equipment. Anions in the
air have a special ability to trap these harmful substances.
The smaller the particle size, the higher the capture rate. It is an effective way to eliminate these pollutants.
CA3000
EN
Fig. 1
Fig. 2
Fig. 3
77
