EN
INSTALLING THE FILTER
Remove the filter from the plastic bag
1. Remove the front cover.
2. Remove the filters.
3. Remove the filters from the package.
Remove the plastic bag from the filters before use.
Installing the filter and front cover
1. There are differences between the inside and the outside of the dust filter 1 (antibacterial cotton filter and HEPA
filter).
Caution: The handle side should be placed outwards.
2. There are differences between the inside and the outside of the absorption filter 2 (activated carbon filter and cold
catalyst filter).
Caution: The handle side should be placed outwards.
3. There are differences between the inside and the outside of the front filter (pre-filter).
Caution: The handle side should be placed outwards.
4. Place back the front cover.
If the front panel is exposed, the appliance will not start.
PREPARATION FOR HUMIDIFICATION
1. Pull out the water tank from the side of the purifier.
2. Remove the humidifying filter from the package.
3. Place the humidifying filter in the water tank.
4. Open the rubber inlet lid.
5. Add about 1 litre of cold water through the hole and fill about 80 % of the water tank.
6. After filling the water, close the lid.
7. Put the tank back in the purifier.
8. This appliance has a humidifying function by evaporation.
If you add water to the tank, the appliance will automatically generate water vapour. The humidification effect is
related to the air flow rate and works better when the appliance is operating at a higher speed. If the water level drops,
the light will flash while the appliance is operating normally. If the water tank is removed, the light stays on and the
appliance stops functioning.
FUNCTIONS
Switching on
When the appliance is connected and in standby mode, press the "POWER" button to switch it on. When the button
is pressed a second time, the appliance switches to standby mode. (In standby mode, the colour is red; when the
appliance is switched on, the colour is green.)
Selecting the operating mode
When the appliance is switched on and the "AUTO" button is pressed, the negative ion generator and the germicidal
lamp start working and the speed changes according to the sensor data. (When operating in automatic mode, the
light will stay on, otherwise it will be off.) Attention: if users change the air flow rate in automatic mode, the appliance
will automatically exit this mode.
78
Relationships between set speed and PM 2.5 PM = solid particles
Speed
1
2
3
4
TIMER: With the appliance switched on, each press of the "TIMER" button adds 1 hour to the timer. When the sum
reaches 12 hours, the next press turns off the timer. (When operating in timer mode, the light will stay on, otherwise
it will be off.)
NEGATIVE ION: With the appliance switched on, pressing the "negative ion" button switches the negative ion mode
on and pressing it again switches it off. (When operating in negative ion mode, the light will stay on, otherwise it will
be off.)
RESET: The appliance has a regular filter change reminder function that works every 320 and 1500 hours. Every
320 hours, the indicator light on the panel will flash, informing the user about cleaning the filter No. 1. After cleaning,
press the "RESET" button for 5 seconds, then the indicator will stop flashing. Every 1500 hours, the indicator light stays
on to inform the user about replacing the filter No. 2 and No. 3. Then press the button for 5 seconds to reset the timer.
The second function of the "RESET" button: With the appliance switched on, press this button and the total working
hours will be displayed on the screen. This is equal to the control of working hours. Because only three digits can
be displayed on the screen, thousands are displayed first, then hundreds, tens, and finally units. Please read them
together.
SLEEP: When the appliance is switched on, it switches to sleep mode 5 seconds after pressing the "SLEEP" button. In
the sleep mode, all the lights go out and the appliance works at the first speed. Press any button to wake it up, then
press "SLEEP" button to exit the sleep mode, or press "SPEED -" / "SPEED +" / "AUTO" button to exit after waking up.
CHILD LOCK: With the appliance switched on, press "CHILD LOCK" to lock all buttons. During this time, no button
responds to pressing while the appliance is still operating as previously set. Press the "CHILD LOCK" button for
5 seconds and the appliance will exit this mode. (When operating in child lock mode, the light will stay on, otherwise
it will be off.)
SPEED +/-: When switched on, press the "SPEED" button to set the airflow speed. The four speeds range from lowest
to highest. After manually changing the speed position, the motor will not be controlled by the sensor and can only
operate in the currently set speed position (the automatic function of the airflow speed button will be cancelled).
Wi-Fi: Enter APP mode: in standby mode, press and hold the Wi-Fi button, the button light flashes, and then goes into
network assignment mode. After a successful assignment, the Wi-Fi button lights up.
CA3000 CA3000
PM 2.5 Light colour Speed
0–50 5
Green
51-80 6
81-100 7
Blue
101-120 8
EN
PM 2.5 Light colour
121-140
Yellow
141-160
161-300
Red
301-500
