Quick Setup:
WX 50, WX 60, and WXC 500 QUICK START
After powering on the device and assigning IP parameters, the next step is to log in to the Web console and run the Quick
Setup program. The first time you log in to the Web console, the Quick Setup program starts automatically and guides you
through initial configuration options for the device.
You can log in to the Web console from any workstation in your network. The Web console supports Microsoft Internet
Explorer version 6.0 (and later). Data is securely transmitted through HTTPS.
To log in to the Web console and run Quick Setup, follow these steps:
From a workstation in your network, start your Web browser and enter the following URL:
https://(IP address of the WX device)
•
Depending on your browser settings, the Security Alert dialog box may appear. Click Yes to proceed.
•
In the Enter Network Password dialog box, type admin for the user name and peribit for the password.
NOTE: This is a factory-configured password for the device. You will be asked to change the default password during the
Quick Setup.
5
Select an Operating Mode.
5
A device can run in Active mode or Profile Mode.
•
Active Mode — Active operation where the device reduces data, accelerates TCP applications, and manages bandwidth.
•
Profile Mode — Passive operation where the device can calculate potential data reduction statistics for all traffic,
individual applications, and specific remote subnets. The actual traffic is not affected.
NOTE: To use Profile Mode, the device's Local interface must be connected to a mirrored port on the switch, and the Remote
interface must be disconnected. If you have installed the device inline, do not select Profile Mode as data will be dropped.
For more information about Profile Mode, refer to the Operator's Guide.
•
Click Next to continue.
