Juniper Networks, Inc.
1194 North Mathilda Avenue
Sunnyvale, CA 94089
USA
1.888.314.JTAC
1.408.745.9500
www.juniper.net
WX 50, WX 60, and WXC 500
QUICK START
Before you begin:
Welcome to the Juniper WX 50, WX 60, and WXC 500 application acceleration platforms.
These 2 rack-unit network infrastructure devices are deployed on the LAN side of the edge
router. Using this quick start card, these devices can be installed and operational in a matter
of minutes.
Inspect the package contents. Refer to the package contents document
enclosed with the product.
Ensure sufficient power is available. Supply circuits should be protected
by a maximum 20A circuit breaker.
Ensure a minimum of 6 inches clearance in the front and back of the
chassis.
Verify that all firewalls between WX devices allow traffic on TCP/UDP
ports 3577 and 3578, and for IPComp, the IP payload compression proto-
col used for reduction tunnels between devices (protocol number 108).
Identify a 10/100 Ethernet LAN port (for a WX 50) or a 10/100/1000 LAN
port (for a WX 60 or WXC 500) that transmits data to your WAN router.
This port is typically from an aggregation switch, or from another LAN
device connected directly to the router.
Obtain a permanent license key. The license key determines the through-
put levels for the device, and properly registers the product. To obtain a
permanent license key, go to https://www.juniper.net/generate_license.

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für Juniper Networks WX 50

  • Seite 1 QUICK START Before you begin: Welcome to the Juniper WX 50, WX 60, and WXC 500 application acceleration platforms. These 2 rack-unit network infrastructure devices are deployed on the LAN side of the edge router. Using this quick start card, these devices can be installed and operational in a matter of minutes.
  • Seite 2: Installation

    Installation: WX 50, WX 60, and WXC 500 QUICK START Set up the chassis. • For rack mount installation, install the supplied brackets, front panel forward, to the sides of the device. • For desktop installation, install the supplied rubber stands in the recessed areas on the bottom of the chassis.
  • Seite 3 • If the LINK LEDs light, the device is properly connected. If the LINK LEDs do not light, toggle the MDI/MDI-X buttons (WX 50 only). • On the WX 60 and WXC 500, the SPEED LEDs indicate 100 or 1000 Mbps connectivity.
  • Seite 4: Quick Setup

    Quick Setup: WX 50, WX 60, and WXC 500 QUICK START After powering on the device and assigning IP parameters, the next step is to log in to the Web console and run the Quick Setup program. The first time you log in to the Web console, the Quick Setup program starts automatically and guides you through initial configuration options for the device.
  • Seite 5 WX 50, WX 60, and WXC 500 QUICK START Registration Server Setup. One device must be designated as the Registration Server. • To designate this device as the registration server, enter a registration server password in the appropriate fields. Do not designate a WX 15 as the registration server (except in test environments).
  • Seite 6 WX 50, WX 60, and WXC 500 QUICK START Advertise Local subnet. By default, the device’s local subnet is not advertised to the other WX devices in the community. As a result, data destined for this subnet is not reduced — even if there is a WX device in the path.
  • Seite 7: Erste Schritte

    WX 50, WX 60 und WXC 500 KURZANLEITUNG Erste Schritte: Willkommen bei den Juniper WX 50, WX 60 und WXC 500 Application Acceleration-Plattformen. Diese Netzwerkinfrastrukturgeräte in zwei Rackhöheneinheiten werden zwischen LAN und Edge Router eingesetzt. Anhand dieser Kurzanleitung können Sie die Geräte in wenigen Minuten installieren und in Betrieb nehmen.
  • Seite 8 Installation: WX 50, WX 60 und WXC 500 KURZANLEITUNG Stellen Sie das Gehäuse auf. • Bei der Befestigung in einem Rack bringen Sie die mitgelieferten Montagewinkel an den Geräteseiten an. Achten Sie darauf, dass die Vorderseite nach vorne zeigt. •...
  • Seite 9 Am WX 60 und WXC 500 weisen die LEDs SPEED auf eine Verbindung von 100 bzw. 1000 MBit/s hin. Die Geschwindigkeit lässt sich am Bedienfeld oder dem CLI überprüfen. Am WX 50 zeigen die LEDs 100M eine 100-MB-Verbindung an. š...
  • Seite 10 Schnellkonfiguration: WX 50, WX 60 und WXC 500 KURZANLEITUNG Nach dem Einschalten des Geräts und dem Zuweisen von IP-Parametern besteht der nächste Schritt im Anmelden bei der Webkonsole und dem Ausführen des Schnellkonfigurationsprogramms. Wenn Sie sich zum ersten Mal bei der Webkonsole anmelden, wird automatisch das Schnellkonfigurationsprogramm gestartet, das Sie durch die Optionen für die Erstkonfiguration...
  • Seite 11 WX 50, WX 60 und WXC 500 KURZANLEITUNG Richten Sie den Registrierungsserver ein. Ein Gerät muss als Registrierungsserver festgelegt sein. • Um das aktuelle Gerät als Registrierungsserver zu bestimmen, geben Sie ein Kennwort für den Registrierungsserver in die dafür vorgesehenen Felder ein. Bestimmen Sie einen WX 15 nicht als Registrierungsserver (außer in Testumgebungen).
  • Seite 12 WX 50, WX 60 und WXC 500 KURZANLEITUNG Aktivieren Sie die Bekanntmachung des lokalen Subnetzes. Standardmäßig wird das lokale Subnetz des Geräts den anderen WX-Geräten in der Community nicht bekannt gemacht. Folglich findet keine Reduktion von Daten statt, die für dieses Subnetz bestimmt sind — selbst dann nicht, wenn sich im Pfad ein WX-Gerät befindet.
  • Seite 13: Démarrage Rapide

    (protocole numéro 108). • Identifiez un port LAN Ethernet 10/100 (pour le WX 50) ou un port LAN 10/100/1000 (pour un WX 60 ou un WXC 500) afin qu’il transmette les données vers votre routeur WAN. Ce port se trouve généralement sur un commutateur d’agrégation ou sur un autre périphérique LAN...
  • Seite 14 Installation : WX 50, WX 60 et WXC 500 DÉMARRAGE RAPIDE Installez le châssis. • Pour réaliser une installation en rack, installez les supports fournis sur les côtés du périphérique, en plaçant le panneau avant vers l’avant. • Pour réaliser une installation sur un plateau, installez les pieds en caoutchouc fournis dans les renfoncements situés sous le châssis.
  • Seite 15 Sur le WX 60 et le WXC 500, les diodes SPEED indiquent une connectivité de 100 ou de 1000 Mbits/s. Pour vérifier la vitesse, utilisez le panneau avant ou les commandes en ligne. Sur les périphériques WX 50, les diodes 100M indiquent une connectivité de 100 Mbits/s. š •...
  • Seite 16: Configuration Rapide

    Configuration rapide : WX 50, WX 60 et WXC 500 DÉMARRAGE RAPIDE Après avoir mis le périphérique sous tension et défini les paramètres IP, l’étape suivante consiste à vous connecter à la console Web et à exécuter le programme de configuration rapide. La première fois que vous vous connectez à la console Web, le programme de configuration rapide démarre automatiquement et vous guide à...
  • Seite 17 WX 50, WX 60 et WXC 500 DÉMARRAGE RAPIDE Configurez le serveur d’administration. Vous devez désigner un périphérique en tant que serveur d’administration. • Pour ce faire, saisissez un mot de passe de serveur d’administration dans les champs appropriés. Ne désignez pas un WX 15 comme serveur d’administration (excepté dans des environnements de test).
  • Seite 18 WX 50, WX 60 et WXC 500 DÉMARRAGE RAPIDE Annoncez le sous-réseau local. Par défaut, l’existence du sous-réseau local d’un périphérique n’est pas annoncée aux autres périphériques WX de la communauté. Par conséquent, les données destinées à ce sous-réseau ne sont pas compressées, en dépit de l’existence d’un périphérique WX sur le chemin.
