2° Set "Voltage %" trimmer to 83.33% since:
250 (V
V% =
300 (V
having wired terminals 7 - 11.
3° Set "Hysteresis %" trimmer (tripping window) to 10% to
obtain a tripping window between 237.5 and 250 V
(250 V -5% = 237.5 V): the relay will trip at 250 V and regular
operation will start again at 237.5 V.
4° Set the "Delay" trimmer
This makes it possible to delay the relay tripping time (1.... 30
sec). (During the delay the "Power on" LED will flash; at the
end of the delay the "Alarm" LED will turn on and the relay will
trip).
V =250V
max
237,5V
V =230V
n
)
max
x 100 = 83,33%
)
limit
Alarm
In allarme
condition
Regular
Normale
funzionamento operation
No alarm because outside
Non in allarme perchè fuori
of hysteresis window
dalla finestra di isteresi
Still in alarm because within
In allarme in quanto all'interno
della finestra di isteresi
the hysteresis window
Selected
Finestra
hysteresis
di isteresi scelta
= 5%
window = 5%
