Start-up
5.2

Mounting

Please read this entire section before starting to
mount the device.
You can use
• the supplied double-sided adhesive strips or
• screws (3.0 x 30 mm) and plugs (5 mm)
to fix it to a wall.
5.2.1

Adhesive strip mounting

Make sure that the mounting surface is smooth,
solid, non-disturbed, free of dust, grease and
solvents and not too cold to ensure long-time
adherence.
For mounting the device using adhesive strips, please
proceed as follows:
• Choose a site for installation.
Place the push-button (A) into the wall mounting
•
bracket (E) until it properly engages into the
bracket (see figure 4).
• Fix the adhesive strips on the back side of the wall
mounting bracket in the provided area on the left
and right. You should be able to read the letters
on the back side (see figure 5).
• Remove the protective film from the adhesive
strips (see figure 6).
• Press the assembled wall-mount remote control
38
